Specifications - Sony MHC-EC50 Marketing Specifications

Micro & mini shelf systems: mini hi-fi system.
Hide thumbs


100 Watts Total: 50 Watts per channel x 2 (RMS 10% THD,
120-10 kHz)
2 Way Main Speakers with huge 6 3/10" Woofers for
Maximum Bass A two driver design helps ensure audio
accuracy by providing a greater frequency range. The
speaker's crossover splits the frequency band into three
ranges: bass frequencies to the woofer, treble frequencies go
to the tweeter and the middle frequencies are sent to a third
drive commonly referred to as the midrange.
3 Disc CD Changer with Play Exchange A feature that allows 2
discs to be changed while the third continues to play.
CD-R/CD-RW with MP3 Playback Capability Plays back MP3
files recorded onto CD-R/RW discs.
Piano Key Single Cassette Often referred to as a "soft-touch"
design, a full-logic transport's controls require less effort to use
than older style mechanical transports.
Tuner with 20 FM/10 AM Station Presets Provides easy access
to the most listened to radio stations.
4 Preset EQ settings Creates enhanced sound modes for
differnt types of music, such as rock and pop.
PC/Audio In for Digital Music Players or PC Input An exciting
new feature that takes music playback beyond tape and CD. It
allows simple plug-and-play integration with a digital music
device or PC via a 2.5 mm jack.
Bass Reflex Speaker System A type of speaker enclosure that
includes a "tuned" port to increase and extend bass response
(by releasing some of the energy created by the inward
movement of the woofer cone).
Synchronized CD/Cassette Dubbing Starts cassette recording
when compact disc playback begins
Two Timer Modes Provides a Sleep and Wake timers for ease of


Type of Use: Shelf System
Tray Type: Tray Loading 3 Disc CD Changer with Play Exchange
(Semiconductor Laser 780nm)
Disc Capacity: 3
Digital-to-Analog Converter: 1 Bit
Frequency Response: CD: 20-20000Hz (±0.5dB); Cassette: 50-
13000Hz (±0.3db)
Format(s) Supported: CD-DA, CD-R/RW, CD's WITH MP3 Playback
Tuning: Auto Scan Radio
Antenna System: AM: Loop Antenna, FM: Lead Antenna
Tape System: 4 Track, 2 Channel Stereo Cassette, CD
Synchronized Recording
Frequency Range: AM: 530-1710kHz; FM: 87.5-108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat
Station Preset(s): 30 (10 AM, 20 FM)
Sound Enhancer: Groove Bass Boost Function, Virtual Surround
Sound Mode
Equalizer: 9 Presets (Rock, Pop, Jazz, Dance, Soul, Oriental,
Reggae, Salsa, Samba), 3 Personal File Settings
Tape Operation: Full Logic Dual Cassette Deck
Tuner Type: FM/AM Superheterodyne Tuner
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1-800-222-7669 •
Convenience Features
Timer Events: Record/Play/Sleep (Wake-up or Fall Asleep To
Music-Select from 10 Timed Shut Offs)
Power Save Mode: Yes
Display: LCD
Remote Control: Yes (Remote Commander®)
Power Requirements: AC 120V, 60Hz
Output Power: 100 Watts Total: 50 Watts per Channel x 2 (RMS
10% THD, 120-10 kHz)
Power Consumption: 205W
Manual: 210W
Battery Type: Remote: "AA" x 2
Power Handling Capacity: With 6 ohms loads, both channels
driven from 120-10000 Hz; rated 150 W per channel-minimum
RMS power, with no more than 10% total harmonic distortion
from 250 milliwatts to rated output.
Speaker System: 3 Way, 3 Unit, Bass Reflex Type
Speaker Dimensions: 2" (5cm)
Woofer Size(s): 5.1" (13cm); 5.1" (13cm) (Subwoofer)
Inputs and Outputs
Analog Audio Input(s): 1 (Rear, Stereo Mini)
Headphone Input(s): 1 (Front, Stereo Mini)
PC Audio Input(s): Yes
Antenna Terminal (AM Loop): 1 (Rear)
Antenna Terminal (FM 75 Ohm): 1 (Rear)
Weight: Speaker: 8 lbs 6 oz (3.8 Kg) (each x 2); Main Unit: 22 lbs 1
oz (10 Kg)
Measurements: Speaker: 9 1/16 x 13 7/12 x 9 1/4" (230 x 345 x
235mm) (each x 2); Main Unit: 11 x 12 4/5 x 16 13/14" (280 x
325 x 430mm)
Supplied Accessories
Instruction Manual
Remote Commander® Remote Control (RM-SC50)
AM Roop Antenna
FM Lead Antenna
UPC Code: 027242681262
1. CD-R/RW media/formats are not universally compatible.
©2006 Sony Electronics Inc.
Reproduction in whole or in part without written permission is prohibited. All rights reserved. Sony, Remote
Commander, and are trademarks of Sony.
Features and specifications are subject to change without notice. Non-metric weights and measures are
Please visit the Dealer Network for current information at
Mini Hi-Fi Component System
Last Updated: 10/08/2007
