Epilog Fusion M2 Manual page 4

Laser Safety Module
Pin Modular (RJ45) plug into the Modular Jack on
the Laser Safety Module.
Fiber
If your engraver is equipped with a Fiber
Laser source, locate the data cable and connect
it to the DB25 Port on the Laser Safety Module.
Secure Part
Place the new Laser Safety Module onto the
mounting studs so that the LED Panel can be
seen from the exterior of the engraver and
replace the Mounting Nuts.
Power on and Update
Power on the engraver and follow the
instructions on the display. Sometimes the
firmware in other parts of the engraver will need
to synchronize and update to the new part. Do
not power off the engraver until the instructed
or the display reads "Job".
Complete
