AERATOR PRO-26

Operator's Manual,

Maintenance Manual,

and

Parts Lists

TURFCO

Aerator PRO-26

Product Number 85395 and 85396

85395 Briggs & Stratton 2.61 kW (3.5 HP) Industrial Plus Engine

85396 Honda 2.98 kW (4.0 HP) GX120 Engine

For Use With Serial Numbers Before G00101

Manual Number 661265 Rev A

DANGER

- IF INCORRECTLY USED THIS MACHINE CAN CAUSE SEVERE INJURY.

THOSE WHO USE AND MAINTAIN THIS MACHINE SHOULD BE TRAINED IN ITS

PROPER USE, WARNED OF ITS DANGERS, AND SHOULD READ THE ENTIRE MANUAL

BEFORE ATTEMPTING TO SET-UP, OPERATE, OR SERVICE THE MACHINE.

TURFCO MFG. INC.

1655 101st. Avenue NE ● Minneapolis, MN. USA 55449-4420

Phone (763) 785-1000 ● FAX (763) 785-0556

1998 Turfco Mfg., Inc.

Table of Contents

Need help?

Do you have a question about the Aerator PRO-26 and is the answer not in the manual?

Questions and answers

Summary of Contents for TURFCO Aerator PRO-26

Page 1 PROPER USE, WARNED OF ITS DANGERS, AND SHOULD READ THE ENTIRE MANUAL BEFORE ATTEMPTING TO SET-UP, OPERATE, OR SERVICE THE MACHINE. TURFCO MFG. INC. 1655 101st. Avenue NE ● Minneapolis, MN. USA 55449-4420 Phone (763) 785-1000 ● FAX (763) 785-0556 1998 Turfco Mfg., Inc.
Page 2: Table Of Contents
TURFCO® is a registered trademark of Turfco Mfg., Inc. Product Records IMPORTANT: Record the information from the serial number plate of your Aerator Pro-26. It will be necessary to furnish your Model Designation, Product Number, and Serial Number when ordering parts.
Page 3: Specifications
Intended Use: The Aerator Pro-26 is a self-propelled tine type aerator. The Aerator Pro-26 is intended to be used for the aeration of the turf or soil at a properly prepared worksite. The Aerator Pro-26 is NOT intended to be used for any purpose other than the aeration of turf. The Aerator Pro-26 is NOT designed for or intended to accept riders.
Page 4: Recognizing Safety Warnings And General Safety Practices
SAFETY AERATOR PRO-26 Recognizing Safety Warnings Used In Manual LOOK FOR THE SAFETY HAZARD WARNING SYMBOL The symbol is used to alert the operator of safety hazards. It is used in conjunction with the words DANGER, WARNING, and CAUTION. DANGER...
Page 5 SAFETY AERATOR PRO-26 Beware of slippery conditions. Wet turf can be frequently for cracks and leaks. encountered on slopes, when turning or stopping, or Pull the starter cord slowly until resistance is felt. Then at higher speeds. pull the cord rapidly to avoid kickback and to prevent Keep hands and feet away from cutting devices and hand or arm injury.
Page 6: Assembly
ASSEMBLY AERATOR PRO-26 Assembly SAFETY FIRST INSTALLATION OF THE TRANSPORT WHEELS STEP 3. Install transport wheels on the wheel pivot WARNING linkage. Wheels and axles should be spaced with TO AVOID SERIOUS INJURY, a ﬂat washer. Secure to wheel pivot linkage with a Remove Wire From Spark Plug Before hairpin.
Page 7 ASSEMBLY AERATOR PRO-26 Assembly CLUTCH SPRING CLUTCH ?S" HOOK CABLE CABLE CLUTCH CLEVIS ADJUSTER PIVOT LINKAGE CLUTCH HANDLE HAIR PIVOT BUSHING FLEXLOC AND FLAT WASHER 3/8-16 X 1-1/8" HEX HEAD SCREW AND FLAT WASHER WHEEL RIGHT SIDE LIFT TUBE AXLE HAIR 3/8-16 X 7/8"...
Page 8: Description
The Aerator Pro-26 is a self-propelled coring tine type The operator controls are located on the handlebar. aerator. The Aerator Pro-26 is intended to be used for the aeration of the turf or soil at a properly prepared They consist of the engine throttle, the clutch handle, and the transport wheels handle.
Page 9: Operation
OPERATION AERATOR PRO-26 Operation Locate and mark all irrigation heads, above and below WARNING ground irrigation control boxes, and any shallow buried TO AVOID SERIOUS INJURY, irrigation lines that may be damaged by the aerating Read and Understand the Entire process.
Page 10: Operating Instructions
Aerator Pro-26 can tip, roll over, or roll back on to ● Inspect all controls for proper operation. the operator, causing serious injury. When aerating ●...
Page 11: Service
SERVICE AERATOR PRO-26 Service position, ensure that the chain and all sprockets WARNING have been cleaned and that the chain seats properly TO AVOID SERIOUS INJURY, on the sprockets. A build-up of dirt on the sprockets Do Not Lubricate Or Adjust The Aerator or chain can cause the chain to become too tight.
Page 12: Parts Lists
PARTS LISTS AERATOR PRO-26 Handlebar Assembly 24 (LEFT LONG END OF SIDE LIFT LIFT TUBE TUBE ONLY) TOWARDS THE BOTTOM PL85395-01 85395 & 85396...
Page 13 PARTS LISTS AERATOR PRO-26 Handlebar Assembly Item Part Description Qty. 660093 Handlebar ....................1 400260 Screw, Hex, 3/8”-16 x 7/8” ..............6 444810 Nut, Hex, 3/8”-16, Flexloc Full ..............10 660104 Handle, Wheel Lift ..................1 446142 Washer, Lock, 3/8” ..................2 452006 Washer, Flat, 3/8” ID x 7/8” OD x 5/64” Thick ........14 658630 Bushing, Pivot ..................2...
Page 14 PARTS LISTS AERATOR PRO-26 Transport Wheels PL85395-02 85395 & 85396...
Page 15 PARTS LISTS AERATOR PRO-26 Transport Wheels Item Part Description Qty. 660091 Tube, Pivot, Wheel, Includes Oilite Bearings ..........1 650586 Bearing, Oilite, Wheel Pivot Tube ............2 400184 Screw, Hex Head, 5/16”-18 x 3/4” ............4 444808 Nut, Hex, 5/16”-18 Flexloc ..............4 661281 Shaft, Wheel Pivot ..................1...
Page 16 PARTS LISTS AERATOR PRO-26 Tine Reel Assembly TINE CARRIAGE BOLTS FORWARD ROTATION PL85395-03 SPROCKET END OF TINE REEL Item Part Description Qty. 661234 Tine Reel ....................1 87305 Tine, 1 Each ..................42 658599 Bolt, Carriage, 5/16”-18 x 1-1/2” ............84 658600 Nut, Hex, 5/16”-18 Thin Nylock .............84 658541 Bearing, Flange, Includes Set Screws ............2...
Page 17 PARTS LISTS AERATOR PRO-26 Front Drum Assembly PL85395-06 Item Part Description Qty. 661263 Shaft, Tank ....................1 658595 Gasket, 4-1/2” ..................1 658593 Ring, Split ....................2 661052 Tank, Water, Pro-26 Aerator, Long ............1 658538 Plug, Expansion, 1” ................1 658596 Gasket, 2-7/8” ..................1 658592 Flange, Small, 2-7/8”...
Page 18 PARTS LISTS AERATOR PRO-26 Jackshaft Assembly PL85395-05 Item Part Description Qty. 661231 Jackshaft ....................1 655774 Bearing, Flange, Includes Set Screws ............2 499051 Screw, Set, 1/4”-28 x 1/4” ...............4 458021 Ring, Retaining, 1” External ..............2 658240 Bolt, Carriage, 5/16”-18 x 3/4” ..............4 444808 Nut, Hex, 5/16”-18 Flexloc Full ...............4...
Page 19 PARTS LISTS AERATOR PRO-26 V-Belt Clutch, Chain and Chain Idler Assemblies PL85395-07 Item Part Description Qty. 661228 Arm, Clutch .....................1 458013 Ring, Retaining, 3/4” External ..............2 658552 Block, Bearing ..................4 441632 Bolt, Carriage, 3/8”-16 x 2-1/4” ...............4 452008 Washer, Flat, 7/16” ID x 1” OD x 5/64” Thick ..........6 444810 Nut, Hex, 3/8”-16, Flexloc Full ..............5...
Page 20 PARTS LISTS AERATOR PRO-26 Engine and Front Bumper PL85395-08 Item Part Description ............. Qty. 658636 Engine, Briggs and Stratton, 2.61 kW (3.5 HP) Industrial Plus with 6:1 Gear Reducer ................1 658646 Deﬂector, Exhaust...................1 658602 Engine, Honda, 2.98 kW (4.0 HP) GX120 with 6:1 Gear Reducer ..1 400192 Screw, Hex Head, 5/16”-18 x 1-1/2”...
Page 21 PARTS LISTS AERATOR PRO-26 Guard Assemblies PL85395-09 Item Part Description ............. Qty. 660111 Guard, Belt ....................1 658648 Pin, Belt Guide ..................1 658649 Push Nut, 1/4” Cap .................2 400108 Screw, Hex, 1/4”-20 x 3/4” ..............12 446128 Washer, Lock 1/4” .................12 452002 Washer, Flat, 1/4”...
Page 22 1 - MANUAL (NOT SHOWN) Item Part Description Qty. 661265 Operator’s Manual “Rev A” and Parts List, Aerator PRO-26 ....1 661700 Decal, Dashboard and Throttle ...............1 661703 Decal Set, Aerator Pro-26, Includes Items 4 Thru 13 ......1 Decal, Clutch Control Handle ...............1 Turfco Aerator Pro-26, Product Identiﬁcation, Large ......2...
Page 23: Decals
PARTS LISTS AERATOR PRO-26 Decals Aerator PRO-26 Product Number 85396 30 mm 4.76 Km/h 2.98 LpA = 88.1 dBA LWA = 100.7 dBA 15° MAX. 174.64 Kg A. Dashboard Decal B. Throttle Decal CE (EUROPEAN) C. Product Identification Decal DOMESTIC D.
Page 24 TURFCO MFG INC 1655 101st Ave NE, Minneapolis, Minnesota USA 55449-4420 Phone (763) 785-1000 FAX (763) 785-0556 E-mail service@turfco.com Internet www.turfco.com Manual Number 661265 Rev A AERATOR PRO-26 Printed In USA Product Number 85395 and 85396 11/98 1C...
