TABLE OF CONTENTS Safety Instruc� Introduc Iden� i y f Installa� n Moun ng • Electrical Connec�on • Compa�ble Logic Control • Limit Switch Connec�ons • User Instruc�ons (Arabic) 10-11...
SAFETY SYMBOL AND SIGNAL WORD REVIEW Safety symbol and signal word review This commercial door opener has been designed and tested to offer safe service provided it is installed, operated, maintained and tested in strict accordance with the instruc�ons and warnings contained in this manual. When you see these Safety Symbols and Signal Words on the WARNING following pages, they will alert you to the possibility of...
INTRODUCTION Congratula�ons on your purchase of the Heavy Duty Roller Shu�er Operator. For more than 50 years, we have been producing industrial mechanical operators that are well known for their proven reliability & robust design. IDENTIFYING YOUR OPERATOR Output sha Motor terminal box Limit enclosure ACEM...
INSTALLATION Moun ng the Unit The Heavy Duty operator is typically fl ag mounted below the door drum so that the operator sha� points toward the door opening and lies beneath the sprocket of the door drum. For moun�ng you will need to either secure the operator to the roller shu�er head plate with prepared holes or slots, or use a moun�ng plate that will need fi...
Page 6
INSTALLATION Mounting the Unit (continued) Breather plug must be removed a�er installa- �on 150mm Minimum Room needed for safe chain opera�on Side room to imposing structures (see le�) Note: The operator limit housing requires adequate clearance to allow setting of limit cams during installation. 150mm is the minimum recom- mended clearance between wall and lid.
INSTALLATION CAUTION When Securing the Heavy Duty Operator with the 4 x ½’ x 1 ¼’ long fasteners (based on a 12mm moun�ng plate) and spring washers provided, it is cri�cal to ensure that the applied torque is between 80-90Nm. When moun�ng through thicker sec�ons, ensure a minimum of 20mm of screw thread is engaged with the female thread.
INSTALLATION Limit Switch Connec�on Limit switches are pre-wired to the motor terminal box for easy access. The limit switches must be connected to the controller via the NORMALL CLOSED (N/C) and COMMON (COM) terminals located inside this motor terminal box as shown. SETUP AND ADJUSTMENT The limit cams are located in the limit enclosure box shown.
Page 9
Automa�c Chain Engagement Mechanism (ACEM) The patented ACEM features allows the use of the hand chain in the event of a power failure. Simply pull on the hand chain in either direc�on to operate the door manually. اﻟﺻﻖ اﻟدﻟﯾل اﻹرﺷﺎدي ﻟﻠﺑﺎب ﺑﺎﻟﻘرب ﻣن اﻟﺳﻠﺳﻠﺔ...
