- Page 1 Basler aviator CAMERA LINK INFORMATION FOR FRAME GRABBER DESIGNERS Document Number: AW000831 Version: 08 Language: 000 (English) Release Date: 23 October 2013...
- Page 2 Basler customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Basler for any damages resulting from such improper use or sale. Warranty Note Do not open the housing of the camera.
- Page 3 Contacting Basler Support Worldwide Europe: Basler AG An der Strusbek 60-62 22926 Ahrensburg Germany Tel.: +49-4102-463-515 Fax.: +49-4102-463-599 support.europe@baslerweb.com Americas: Basler, Inc. 855 Springdale Drive, Suite 203 Exton, PA 19341 U.S.A. Tel.: +1-610-280-0171 Fax.: +1-610-280-7608 support.usa@baslerweb.com Asia: Basler Asia Pte. Ltd.
-
Page 5: Table Of Contents
............21 Basler aviator Camera Link... - Page 6 Table of Contents AW00083108000 Basler aviator Camera Link...
-
Page 7: Camera Link Implementation
Camera Link Implementation 1 Camera Link Implementation The Basler aviator Camera Link camera transmits Camera Link data in a fashion similar to a National Semiconductor DS90CR287 device. For Camera Link receivers on your frame grabber, we recommend that you use a National Semiconductor DS90CR288, a National Semiconductor DS90CR288A or an equivalent. -
Page 8: Pin Assignments And Numbering For The Mdr Connector
CC2- None None None None None CC4+ Input RS-644 Not assigned LVDS CC4- Table 1: Pin Assignments for MDR Connector One Pins 1, 13, 14, and 26 are all tied to ground inside of the camera. Basler aviator Camera Link... - Page 9 AW00083108000 Camera Link Implementation Fig. 1: Camera / Frame Grabber Interface Basler aviator Camera Link...
-
Page 10: Camera Link Input Signals
ExFSTrig signal on the CC1 input in the Camera Link interface (pins 9 and 22 of the MDR connector) as specified in the Camera Link standard. The camera can also be programmed to accept the ExFSTrig signal on CC2 or CC4. Basler aviator Camera Link... - Page 11 ExFSTrig signal is 1 µs and the minimum low time is also 1 µs. The ExFSTrig signal is typically supplied to the camera by the frame grabber board. For details about using a frame start trigger with aviator cameras, refer to the aviator User’s Manual (AW000830xx000). Basler aviator Camera Link...
-
Page 12: Camera Link Output Signals
The available pixel formats and the bit assignments are shown in detail in Table 2. The bit assignments comply with the Camera Link standard. Basler aviator Camera Link... - Page 13 Data Valid Data Valid Data Valid Spare TxIN23 RxOut23 Not Used Not Used Not Used Strobe TxINCLK RxOutClk Pixel Clock Pixel Clock Pixel Clock Table 2: Bit Assignments for Two Tap Output Modes (Transmitter Circuit X) Basler aviator Camera Link...
- Page 14 Camera Link Implementation AW00083108000 Basler aviator Camera Link...
-
Page 15: Pixel Data Output
2.2 Pixel Data Output Timing The Camera Link pixel clock speed on all aviator Camera Link models is selectable. The available pixel clock speeds are shown in Table 3. Camera Link Pixel Clock Setting... -
Page 16: Camera Link Tap Geometry
Camera link interface. On all Basler aviator cameras, the Camera Link tap geometry can be set to 1X-1Y, 1X2-1Y or to 1X-2YE. -
Page 17: 1Y Tap Geometry
The pixel clock is used to time data transmission. As shown in Figure 3 on page 12, the camera transmits data on each rising edge of the pixel clock. Tap 1 W = width H = height Fig. 2: 1X-1Y Tap Geometry Basler aviator Camera Link... - Page 18 On the next pixel clock cycle, the line valid and data valid bits will still be high. On this clock cycle, data stream D0 will transmit data for pixel 3 in line 1. This pattern will continue until all of the pixel data for line 1 have been transmitted. Basler aviator Camera Link...
- Page 19 Per default the inter-line delay value is set to 4. You can adapt the inter-line delay value to your requirements. For information about how to configure the inter-line parameter, see the aviator Camera Link User’s Manual (AW000830xx000). Basler aviator Camera Link...
-
Page 20: 1X2-1Y Tap Geometry
The pixel clock frequency depends on the current setting of the camera’s Camera Link Clock Speed parameter. Tap 1 Tap 2 W = width H = height Fig. 4: 1X2-1Y Tap Geometry Basler aviator Camera Link... - Page 21 On the next pixel clock cycle, the line valid and data valid bits will still be high. On this clock cycle, data stream D0 will transmit data for pixel 3 in line 1 and data stream D1 will transmit data for pixel 4 in line 1. Basler aviator Camera Link...
- Page 22 Per default the inter-line delay value is set to 4. You can adapt the inter-line delay value to your requirements. For information about how to configure the inter-line parameter, see the aviator Camera Link User’s Manual (AW000830xx000). Basler aviator Camera Link...
-
Page 23: 2Ye Tap Geometry
The pixel clock frequency depends on the current setting of the camera’s Camera Link Clock Speed parameter. Tap 1 H/2+1 H/2+1 H/2+1 H/2+1 W =width H = height Tap 2 Fig. 6: 1X-2YE Tap Geometry Basler aviator Camera Link... - Page 24 On this clock cycle, data stream D0 will transmit data for pixel 2 in line 1 and data stream D1 will transmit data for pixel 2 in line H. On the next pixel clock cycle, the line valid and data valid bits will still be high. Basler aviator Camera Link...
- Page 25 Per default the inter-line delay value is set to 4. You can adapt the inter-line delay value to your requirements. For information about how to configure the inter-line parameter, see the aviator Camera Link User’s Manual (AW000830xx000). Basler aviator Camera Link...
- Page 26 Pixel Data Output AW00083108000 Basler aviator Camera Link...
-
Page 27: Revision History
23 Oct 2013 New cover photo. Added document ID number in headers. Inserted new Basler logo and new aviator cover photo on the front page. Updated the mail addresses and the Asian contact address. Changed Basler Vision Technologies to Basler AG. - Page 28 Revision History AW00083108000 Basler aviator Camera Link...
