- Page 1 Basler aviator QUICK INSTALLATION GUIDE FOR GigE CAMERAS Document Number: AW000977 Version: 03 Language: 000 (English) Release Date: 15 January 2015 Preliminary The information in this document is preliminary and all contrnt is subject to change.
- Page 2 Basler customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Basler for any damages resulting from such improper use or sale. Warranty note Do not open the housing of the camera.
-
Page 3: Contacting Basler Support Worldwide
Contacting Basler Support Worldwide Europe Basler AG An der Strusbek 60 - 62 22926 Ahrensburg Germany Tel. +49 4102 463 515 Fax +49 4102 463 599 support.europe@baslerweb.com The Americas Basler, Inc. 855 Springdale Drive, Suite 203 Exton, PA 19341 Tel. +1 610 280 0171 Fax +1 610 280 7608 support.usa@baslerweb.com... - Page 5 64 bit Windows 8 32 bit Windows 8.1 64 bit Windows 8.1 That you will be connecting the aviator GigE camera directly to a GigE network card in the PC. That the network card will be set to use automatic IP configuration.
-
Page 6: General Preparations
A standard Ethernet patch cable. We recommend the use of a category 6 or category 7 cable that has S/STP shielding. You should perform the software installation procedure first and the hardware installation procedure second. For more information about aviator GigE camera models, see the aviator GigE User’s Manual (AW000976). Basler aviator GigE... -
Page 7: Installation Procedures
Software Suite To install the Basler pylon Camera Software Suite: 1. If you have old Basler pylon software installed on your system, make sure to uninstall the soft- ware. For more information about uninstalling Basler pylon software, see the Installation and Setup Guide for Cameras Used with Basler pylon for Windows (AW000611). - Page 8 12. On the Ready to Install the Program page, click the Install button. 13. On the Setup Wizard Completed page, click the Finish button. The installation program has added shortcuts on the desktop for the Basler pylon Viewer and the Basler pylon IP Configurator.
-
Page 9: Disabling The Windows Firewall
Quick Installation Guide for GigE Cameras 2.2 Disabling the Windows Firewall The Basler pylon software requires the Windows firewall to be disabled for all interfaces where cameras are connected, with the exception indicated below. You do not necessarily need to disable the Windows firewall. - Page 10 Windows Firewall with Advanced Security on Local Computer Properties... window. 3. Select the tab for the profile where you want to disable firewall protection. You will typically disable firewall protection for the Public Profile when a camera is directly connected to the network interface. Basler aviator GigE...
- Page 11 Prompt (Admin). This will run the command shell as an administrator shell. 2. Enter netsh advfirewall set allprofiles state off 3. Press the Enter key. The firewall is disabled for all profiles. It is not possible to use netsh for disabling the firewall for selected connections only. Basler aviator GigE...
-
Page 12: Installing The Hardware
Every time you remove or replace the plastic cap, a lens, or a lens adapter, make sure that the camera is pointing down. Never apply compressed air to the camera. This can easily contaminate optical components, particularly the sensor. Basler aviator GigE... -
Page 13: Installation
DHCP server or use fixed IP addressing. This would make the IP address acquisition process much faster. For more information about IP addressing, see the Installation and Setup Guide for Cameras Used with Basler pylon for Windows (AW000611). Basler aviator GigE... -
Page 14: Changing Camera Settings
2. Open the lens aperture on your camera halfway by choosing an intermediate f-number. 3. Start the pylon Viewer by clicking the pylon Viewer icon on your desktop. The pylon Viewer will open as shown below and you should see an entry in the Devices tree for your aviator camera. - Page 15 Also notice the User Level setting below the Features pane. Choose the Beginner, Expert, or Guru level to display the basic, intermediate, or advanced camera parameters respectively. If you don’t have previous experience with Basler digital cameras, we suggest that you start as a beginner.
- Page 16 To decrease the bandwidth used by the camera carry out some adjustments as indicated below. For more detailed information, see the Installation and Setup Guide for Cameras Used with Basler pylon for Windows (AW000611) and the aviator GigE User’s Manual (AW000976).
- Page 17 Notice how the changes affect the brightness of the images. 11. Now that you have started to learn your way around the pylon Viewer, you can look through the aviator GigE camera user’s manual and use the viewer to adjust the other parameters associated with the camera features.
- Page 18 Quick Installation Guide for GigE Cameras AW00097703000 Basler aviator GigE...
-
Page 19: Revision History
Initial release of this document for series production cameras. AW00097703000 15 Jan 2015 Updated email addresses for technical support. Updated Basler contact address for Asia. Added export compliance information. Updated pylon 4-related language conventions. Removed Microsoft Windows XP and Vista as supported operating systems. - Page 20 Quick Installation Guide for GigE Cameras AW00097703000 Basler aviator GigE...
