- Page 1 UTC Controller User’s Manual V1.0.3...
- Page 2 Foreword General This User’s Manual (hereinafter referred to as the “Manual”) introduces functions, features, battery installation and mode switching of the UTC (up the coax) controller (hereinafter referred to as the “Controller”). Safety Instructions The following categorized signal words with defined meaning might appear in the Manual.
- Page 3 website. If there is inconsistency between paper manual and the electronic version, the electronic version shall prevail. All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Manual. Please contact the customer service for the latest program and supplementary documentation.
- Page 4 Table of Contents Foreword ..............................I 1 Introduction ............................1 2 Battery Installation ..........................2 3 Mode Switching ............................. 3 Table of Contents...
- Page 5 Introduction The Controller is installed between HDCVI camera and DVR (digital video recorder) through coaxial cable. After installing HDCVI camera and connecting it to DVR, you can set up the camera by the Controller. The Controller has the following features: Switch among multiple video formats: CVI, AHD, TVI, and CVBS.
- Page 6 Battery Installation CAUTION Put batteries into the battery holder correctly according to their anodes and cathodes. Use two new AAA alkaline dry batteries. Take the batteries out of the Controller in case of battery leakages if the Controller is not used for a long period.
- Page 7 Switching Mode Two modes are available for the Controller: Mode A and Mode B. Mode A: You can switch among four video formats: CVI, CVBS, AHD, and TVI. Mode B: You can adjust OSD menu and realize zoom control in CVBS video format. You can press and hold ENTER + CVI for 8 s to switch between Mode A and Mode B.
- Page 8 Connector/Button Function In Mode A: CVBS video format. It corresponds to red indicator. ③ In Mode B: Adjust OSD information and realize zoom control. In Mode A: TVI video format. It corresponds to green indicator. ④ In Mode B: Adjust OSD information and realize zoom control.
- Page 9 In Mode B, to zoom in/out, you need to exit from OSD menu first by selecting Exit on OSD menu. In Mode B, if there is no operation for 30 s, the Controller enters sleep mode. After pressing ENTER to wake up the Controller, it automatically enters Mode A, and the red indicator glows.
