PORTABLE AIR CONDITIONER
INSTRUCTION MANUAL
CATALOG NUMBER
BPT05WTBA
BPT06WTB
BPT07WTB
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can't find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Black+Decker BPT05WTBA
Summary of Contents for Black+Decker BPT05WTBA
- Page 1 PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON. If you have a question or experience a problem with your BLACK+DECKER purchase, go to www.blackanddecker.com/instantanswers If you can’t find the answer or do not have access to the Internet, call 844-299-0879 from 10:30 a.m.
-
Page 2: Table Of Contents
Before You Call For Service ..........................25 Customer Service ..............................25 Troubleshooting ..............................26 Limited Warranty ...................................27 PRODUCT REGISTRATION Thank you for purchasing our BLACK+DECKER product. This Model number easy-to-use manual will guide you in getting the best use of your air conditioner. Serial number Remember to record the model and serial numbers. -
Page 3: Safety Information
SAFETY INFORMATION DANGER WARNING CAUTION DANGER - Immediate hazards WARNING - Hazards or unsafe CAUTION - Hazards or unsafe which WILL result in severe practices which COULD result in practices which COULD result in personal injury or death severe personal injury or death minor personal injury IMPORTANT SAFETY INSTRUCTIONS WARNING... - Page 4 SAFETY INFORMATION HANDLING ALKALINE BATTERIES WARNING When handling alkaline batteries, basic safety precautions should be followed, including the following Should fluid from the battery accidentally get into your eyes, there is a threat of loss of eyesight, do not rub them. Immediately rinse your eyes with clean tap water and then consult a physician immediately.
-
Page 5: Grounding Instructions
SAFETY INFORMATION GROUNDING INSTRUCTIONS ELECTRICAL REQUIREMENTS In the event of malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. The appliance must be connected to a cord having an equipment- grounding conductor and a grounding plug. -
Page 6: Lcdi Power Cord And Plug
SAFETY INFORMATION LCDI POWER CORD AND PLUG This air conditioner is equipped with an LCDI (Leakage Current Detection and Interruption) power cord that is required by UL. This power supply cord contains state-of-the-art electronics that sense leakage current. If the cord is damaged and leakage occurs, power will be disconnected from the unit. -
Page 7: Safety Guidelines
SAFETY INFORMATION SAFETY GUIDELINES To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. ALWAYS DO THIS NEVER DO THIS ENERGY SAVE •... - Page 8 SAFETY INFORMATION OPERATING CONDITION The air conditioner must be operated within the temperature range indicated below: NOTE: · Unit performance may be affected when in use outside of these operating temperatures. MODE ROOM TEMPERATURE 64˚F (18˚C) ~ 95˚F (35˚C) COOL DEHUMIDIFY 64˚F (18˚C) ~ 95˚F (35˚C) Page 8...
-
Page 9: Set Up & Use
SET UP & USE PARTS & FEATURES Control Panel and Remote Control Sensor Air Outlet Grill Filter Handles Dehumidification Drain Air Exhaust Hose Housing Plug Intake Grill Condensation Drain Castors (4) Air Exhaust Hose Hose Outlet Hose Inlet Locking Screw Window Bracket Drain Hose Drip Pan... -
Page 10: Specifications
SET UP & USE SPECIFICATIONS BPT05WTBA Unit dimensions (W x D x H): 16.54” x 12.2” x 27.56” Unit weight approx.: 52.9 lbs. BPT06WTB Unit dimensions (W x D x H): 16.54” x 12.2” x 27.56” Unit weight approx.: 53.9 lbs. -
Page 11: Window Slider Kit Installation
SET UP & USE WINDOW SLIDER KIT INSTALLATION Your window slider kit has been designed to fit most standard “Vertical” and “Horizontal” window applications; however, it may be necessary for you to improvise/modify some aspect of the installation procedures for certain types of window. -
Page 12: Exhaust Hose Installation
SET UP & USE EXHAUST HOSE INSTALLATION The air exhaust hose and hose inlet must be installed or removed from the portable air conditioner in accordance with the way it is being used: COOL, AUTO, DEHUMIDIFY: Air exhaust hose and hose inlet should be connected to the portable air conditioner. -
Page 13: Control Panel
SET UP & USE CONTROL PANEL Display Area Selected Mode Fan Speed Indicator Light Indicator Light Mode Selection Fan Speed Button Selection Button ON/OFF Decrease Temp/Time Increase Temp/Time Button Button Pictures are for illustration purpose only. Your model may or may not have all the features. OPERATING FROM THE CONTROL PANEL The Control Panel enables you to manage all the main functions of the appliance, but to fully exploit its potential, you must use the remote... - Page 14 SET UP & USE COOL MODE DEHUMIDIFY MODE Ideal for hot weather when Ideal for reducing humidity you need to cool the room. To in spring and autumn, during set operation of the appliance rainy spells or in damp rooms, Fig.
-
Page 15: Operating From The Remote Control
SET UP & USE OPERATING FROM THE REMOTE CONTROL BATTERY INSTALLATION (BATTERIES NOT INCLUDED) (1) Slide open the battery compartment cover. (2) Insert 2 × “AAA”batteries as shown. (3) Slide back the battery cover. CAUTION: Use only AAA or IEC R03 1.5V alkaline batteries. Remove the batteries if the remote is not used for a month or longer. - Page 16 SET UP & USE REMOTE CONTROL Dehumidify ˚C / ˚F Cool Remote Signal Auto Fan Speed Child Lock Timer Follow Me Turbo Sleep Function Power Button Button Fan Speed Increase Mode Button Timer Button Decrease ˚C / ˚F Sleep Button Selector Fan Speed Button...
- Page 17 SET UP & USE LED Display Indicators Cooling mode Fan speed Dehumidify mode Auto speed Fan mode Child lock Timer on Timer off Signal Sleep Display tempera- Turbo ture or hours Fahrenheit or Follow me Celsius. POWER BUTTON • Press to Turn Air Conditioner ON or OFF. •...
- Page 18 SET UP & USE DEHUMIDIFY Ideal for reducing humidity. • Keep window and door closed for the best dehumidifying effect. • Exhaust hose attachment is not required to reduce humidity, however it is recommended in very humid rooms so the warm air can be exhausted outside. Draining in Dehumidify mode •...
- Page 19 SET UP & USE TO OPERATE TURBO button, TURBO • Press the Function symbol flashes on button again, the TURBO screen then press the function symbol will stop flashing and will illuminate on the LED screen indicating that TURBO is activated. TO CANCEL TURBO button, TURBO •...
- Page 20 SET UP & USE TIMER BUTTON • The timer can be used to delay the appliance start-up or shutdown. PROGRAMMING START-UP • With the appliance ON select the settings that you would like to program at start-up. Example: COOL Mode, temperature, fan speed. Turn OFF the air conditioner.
- Page 21 SET UP & USE WHEN OPERATING IN COOL MODE • Press the button, and the symbol appears. • Selected temperature will increase by 1°F (1°C) per hour in a 2 hour period. This new temperature will be maintained for the next 6 hours, then the air conditioner will turn off.
-
Page 22: Water Drainage
SET UP & USE WATER DRAINAGE Draining in Cooling Mode. This air conditioner is equipped with auto water evaporation so the water compartment would not typically fill in cooling mode unless there is high humidity. Water drainage will generally only be required at the end of the season (see START-END OF SEASON OPERATIONS in cooling mode.) NOTE: As a safety measure to positively prevent water spillage the air conditioner is equipped with a fail safe device if the water tank fills. - Page 23 SET UP & USE Continuous Draining for Dehumidification Mode. Unplug the unit from the power source. Remove the drain cap located in the back center of the unit. While doing this operation some residual water may spill so have a drip pan (not supplied) to collect the water.
-
Page 24: Cleaning & Care
SET UP & USE CLEANING Before cleaning or maintenance, turn the appliance off by pressing the button button on the remote control. Unplug from the on the control panel or electrical outlet. CLEANING THE CABINET You should clean the appliance with a slightly damp cloth then dry with a dry cloth. -
Page 25: Troubleshooting & Warranty
IMPORTANT DO NOT RETURN THIS PRODUCT TO THE STORE If you have a problem with this product, please contact the BLACK+DECKER Customer Satisfaction Center at 844-299-0879. DATED PROOF OF PURCHASE, MODEL # AND SERIAL # REQUIRED FOR WARRANTY SERVICE IMPORTANT NOTE: Read this manual... -
Page 26: Troubleshooting
TROUBLESHOOTING & WARRANTY Troubleshoot your problem by using the chart below. If the air conditioner still does not work properly, contact BLACK+DECKER customer service center or the nearest authorized service center. Customers must never troubleshoot internal components. TROUBLE POSSIBLE CAUSE... -
Page 27: Limited Warranty
3. If there is damaged due to power line BLACK+DECKER does not warrant that the appliance will work surge, user damage to the AC power properly in all environmental conditions, and makes no warranty... - Page 28 BLACK & DECKER, BLACK+DECKER, the BLACK & DECKER and BLACK+DECKER logos and product names and the orange and black color scheme are trademarks of The Black & Decker Corporation, used under license. All rights reserved.
