ELSA MicroLink ISDN PCI User Manual page 57

You would like to achieve the following using this equipment:
You need a separate business telephone number. The answering machine in the
computer should handle your calls when you are meeting clients.
The fax machine is exclusively for business use. If the computer is off, you would
like the analog fax machine to receive faxes for you. If the computer is on, the faxes
should be received by ELSA-RVS-COM . You would also like to send faxes, either
straight out of your computer's applications, or on paper using the analog fax
machine.
Each of your daughters should have a telephone and subscriber number of her own.
The PBX system should also be so kind as to track the calling charges for your busi-
ness and your children separately.
You have an additional cordless telephone to which you would like to assign a sepa-
rate number for your private use. You would also like to be able to take the cordless
handset into the office with you when nobody else is at home but you're expecting
an important private call nonetheless.
The PBX should permit internal telephone calls or the transfer of calls without
accruing additional connect charges.
What's more, from time to time you need to access your files at home from on the
road using your notebook and EuroFileTransfer.
Here's how to realize your goal:
Connect the PBX system to one of the two S
The analog telephones, answering machine and fax machine are each connected to
an a/b port. The ports for the telephones and the fax are each assigned their own
MSN (1234561 to 1234563) via the PBX. Set the a/b port of the answering machine
to the same MSN as the private family phone.
Connect the ISDN telephone and the PC with the ELSA MicroLink ISDN PCI to the S
bus of the PBX system. Set the ISDN telephone to the next MSN (1234564).
Install ELSA-RVS-COM as the communications software on the computer.
Please note the following when installing:
– Select 'Custom' setup in the Installation Wizard.
– Select the same MSN for the fax as for the analog fax machine on the PBX
(1234563).
– Set the answering machine to the same MSN as the ISDN telephone (1234564).
– Select any MSN for EuroFileTransfer (1234565).
– Activate automatic call answering.
That's it! You're now always available––business or private, by telephone, ans-
wering machine or fax. When your computer is on, it handles incoming faxes and
ISDN Connections
connections of the NTBA.
