Installation Under Os/2 - ELSA MicroLink ISDN PCI User Manual

10 Installation
– ELSA Cards
If your kernel supports loading drivers as modules, mark this option for the new
entries.
Once the kernel has been patched with the new drivers, compile the new kernel.
Ensure that the new kernel loads the next time you boot the system.
ISDN configuration
Once you have loaded the new kernel, you can set the ISDN parameters in the
network configuration. Select the card type 'ELSA QuickStep 1000 PCI'.
Further help
If you're not feeling very confident yet with the installation of the drivers, please
refer to the help in your distribution. The files 'ISDNQUICK.html' and 'DE-ISDN-
HOWTO.html' on the included CD contain detailed information on this topic. Current
versions can generally be found on the Web sites of the distributors.

Installation under OS/2

Before you start OS/2, insert the ELSA MicroLink ISDN PCI CD into the CD-ROM
drive. Use the file manager to run the installation file for your product (e.g. from
DRIVER/1000/OS2/ INSTALL.EXE).
After selecting the language for the installation, the window 'ELSA ISDN driver' will
appear. The following settings can be made in this window:
– Confirm the target directory, or change it if you wish to use another.
– Select ISDNmonitor (recommended). This placed the ISDNmonitor program in
Finally click on Install. The required files will now be copied. Confirm the subse-
quent message with OK and restart your computer. The ELSA MicroLink ISDN PCI
board is now installed under OS/2.
ISDNmonitor can be used to ensure that the drivers were properly installed after you
have restarted your computer. In the 'ISDNmonitor' window, click on the upper left-hand
corner and the menu item Information. If the program ISDNmonitor does not start, it is
most likely that the CAPI driver was not installed properly.
ELSA MicroLink ISDN PCI
the Startup program group.
