SPECIFICATIONS

Inputs:
Channel 1: NPN, PNP, Pulse or Dry Contact
Level 0: 0.0 up to 1.0 Volts
Level 1: 2.0 up to 24.0 Volts
Max. frequency: 4000 Hz for NPN, PNP and Pulse
20 Hz for dry-contact (internal De-bounce)
Input Impedance:
NPN, PNP and Pulse: 105 kΩ
Dry contact: Capacitance of 100 nF
Maximum counting: 65535 per period.
Channel 2: 0-20 mA, 4-20 mA, 0-50 mV and 0-10 Vdc,
internally selectable.
Input 2 resolution: 14 bits or 16.384 levels.
Input 2 accuracy: 0.2% of range input signal.
Input Impedance:
0-20 mA and 4-20 mA: 120 Ω
0-50 mV: >>10 MΩ
0-10 Vdc: >120 kΩ
Memory capacity: 64000 (64k)
Interval between readings: Minimum: 1 second, maximum: 18 hours
External battery switch time: 0 to 10 s
Power: 3.6 V lithium battery (1/2 AA)
Estimated autonomy: 200 days with one weekly download and 5
minutes measuring interval. Battery life
depends heavily on data retrieval
frequency.
Working temperature: From –40°C to 70°C.
Protection: IP65 and IP67 models (see lateral label on product)
Material : ABC + PC case, Polycarbonate film.
Dimensions : 60 x 70 x 35 mm

PACKAGE CONTENTS

Besides this manual, the user must check if the items below
accompany the product.
• The electronic logger LogBox-DA;
• Two cables for sensor wiring (IP67 model only).

WARRANTY

Warranty conditions are
www.novusautomation.com/warranty.
NOVUS AUTOMATION
available on our website
LogBox-DA Datalogger
7/7
