INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Radiant Infrared Electric Heater
–
Aura Carbon Fiber Wall Mount Electric Heater
Model n◦ CF15120B
MODELS
VOLTAGE
TOTAL POWER (W)
CURRENT(AMPS)
CF15120B
120
1500
12.5
FIRE/EXPLOSION HAZARD WARNING
NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES
During operation, always ensure combustible materials are kept at a safe distance from the heater
body and from the emitted radiant energy. This heater is not intended for use in hazardous areas where
flammable vapours, gases, liquids or other combustibles are present. Failure to do so can result in
personal injury/or property damage.
FOR INDOOR AND OUTDOOR COMMERCIAL AND RESIDENTIAL USE
INFORESIGHT CONSUMER PRODUCTS INC. * 125 TRADERS BLVD #4 * MISSISSAUGA, ONTARIO * 905-568-7655
1
Advertisement
Related Manuals for Aura CF15120B
Summary of Contents for Aura CF15120B
- Page 1 INSTALLATION, OPERATION AND MAINTENANCE MANUAL Radiant Infrared Electric Heater – Aura Carbon Fiber Wall Mount Electric Heater Model n◦ CF15120B MODELS VOLTAGE TOTAL POWER (W) CURRENT(AMPS) CF15120B 1500 12.5 FIRE/EXPLOSION HAZARD WARNING NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES During operation, always ensure combustible materials are kept at a safe distance from the heater body and from the emitted radiant energy.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1- SAFETY ................................... 3 2- INSTALLATION INSTRUCTIONS ..........................5 2 - OPERATING INSTRUCTIONS ..........................7 2.2.1 Operation of the Remote Control ...................... 8 3 - MAINTENANCE ..............................9 4 - GROUNDING INSTRUCTIONS ........................... 11 5 - Limited Express Warranty..........................13 WARNINGS THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, AND FAILURE TO FOLLOW WARNINGS AND INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, OR INJURY. -
Page 3: 1- Safety
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. 1 - SAFETY WARNING: FIRE OR EXPLOSTION HAZARD •... - Page 4 Do not use the heater if it has been dropped or damaged in any way. Ensure the emitter is not cracked or chipped visually. Contact an authorized Aura dealer for support. SAVE THESE INSTRUCTIONS...
-
Page 5: 2- Installation Instructions
AURA infrared heaters produce radiant heat that warms people and objects, rather than the air around them. The heater can be wall mounted and includes brackets which allow the user to direct the infrared heat where desired. - Page 6 ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3. Use a proper electrical connection box 4. Supply voltage and frequency must correspond to the electrical rating indicated on unit’s information plate WALL-MOUNTED INSTALLATION 1.
-
Page 7: Operating Instructions
ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3. -
Page 8: Operation Of The Remote Control
MANUAL MODE When the manual mode is selected, the heater will operate at 100% of rated power. REMOTE MODE The remote control must be pointed in the direction of the receiver on the heater body (located on the front face) and must be used within a maximum distance of 6 m. In remote mode the heater has 6 power levels. -
Page 9: Maintenance
2. The heater can be still used normally in the event the remote control is misplaced, however it must be used in manual mode. Contact your local authorized Aura Dealer for remote replacement. 3. The remote-control function may not work if there is a barrier between the remote control and heater. - Page 10 REPLACING THE EMITTER Contact your distributor for the correct replacement emitter, providing the model number and rating from the rating label. Using an incorrect replacement emitter can cause the heater to fail. Notice: Read through the Emitter replacement procedure below before beginning the replacement. For easier replacement, remove the heater from the wall or ceiling.
-
Page 11: Grounding Instructions
8. Insert the new emitter through the reflector 9. Connect the new emitter to the terminals of openings. Insert the Reflector Shields and bend the heater; screw in the protective plastic caps the tabs back into place. The Reflector Shields hold the emitter in the correct position during operation. - Page 12 Due to ongoing product improvements, specifications and dimensions are subject to change and correction without notice and without incurring obligations. Determining the application and suitability for use of any product is the responsibility of the installer. Additionally, the installer is responsible for verifying dimensional data on the actual product prior to beginning any installation preparations.
-
Page 13: Limited Express Warranty
6 - LIMITED EXPRESS WARRANTY Limited Express Warranty AURA® Infrared Heaters RESIDENTIAL INSTALLATION/USE: purchase. The consumer must retain a receipted bill of sale as proof of LIMITED ONE (1) YEAR PARTS WARRANTY warranty period. Without this proof, the express warranty begins on the Inforesight Consumer Products Inc.
