INSTALLATION, OPERATION AND MAINTENANCE MANUAL
MODELS
DS15120B
DS24240B
DS32240B
DS32208B
During operation, always ensure combustible materials are kept at a safe distance from the heater
body and from the emitted radiant energy. This heater is not intended for use in hazardous areas where
flammable vapours, gases, liquids or other combustibles are present. Failure to do so can result in
personal injury/or property damage.
FOR OUTDOOR COVERED OR INDOOR USE, IN BOTH COMMERCIAL AND RESIDENTIAL
INFORESIGHT CONSUMER PRODUCTS INC. * 125 TRADERS BLVD #4 * MISSISSAUGA, ONTARIO * 905-568-7655
Radiant Infrared Electric Heater
Aura Shadow No-Light Electric Heater
VOLTAGE (V)
120
240
240
208
FIRE/EXPLOSION HAZARD WARNING
NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES
LOCATIONS IN MODERATE CLIMATES
TOTAL POWER (W)
1500
2400
3200
3200
CURRENT(AMPS)
12.5
10
13.3
15.4
1
Advertisement
Table of Contents
Related Manuals for Aura DS15120B
Summary of Contents for Aura DS15120B
- Page 1 INSTALLATION, OPERATION AND MAINTENANCE MANUAL Radiant Infrared Electric Heater Aura Shadow No-Light Electric Heater MODELS VOLTAGE (V) TOTAL POWER (W) CURRENT(AMPS) DS15120B 1500 12.5 DS24240B 2400 DS32240B 3200 13.3 DS32208B 3200 15.4 FIRE/EXPLOSION HAZARD WARNING NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES During operation, always ensure combustible materials are kept at a safe distance from the heater body and from the emitted radiant energy.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY ................................3 INSTALLATION INSTRUCTIONS ........................5 INSTALLATION CLEARANCES – WALL MOUNT .................... 5 INSTALLATION CLEARANCES – CEILING MOUNT ..................6 INSTALLATION ON HIGH CEILINGS ......................7 ELECTRICAL INSTALLATION ......................... 8 WALL-MOUNTED INSTALLATION ........................ 8 CEILING MOUNTED INSTALLATION ......................9 ADJUSTING DIRECTIONAL POSITIONING ....................10 MAINTENANCE .............................11 CLEANING ..............................11... -
Page 3: Safety
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. 1 - SAFETY WARNINGS WARNING: FIRE OR EXPLOSION HAZARD... - Page 4 ● This product must be installed by a certified cracked or chipped visually. Contact an authorized electrician and must adhere to all local, state and Aura dealer for support. national electric codes (NEC) ● Do not use the heater if the power cord is damaged.
-
Page 5: Installation Instructions
AURA infrared panel heaters produce both radiant and convective heat that warms people and the air around them. This heater includes standard 4” brackets which allow the user to direct the radiant heat where desired. -
Page 6: Installation Clearances - Ceiling Mount
0.6m and 1.2m) to satisfy optimal mounting heights. Minimum Installation Clearances, Ceiling Mount Heater Model Floor (Measured to bottom of heater) Ceiling Adjacent Walls DS15120B 6’7” (2.1m) – USA DS24240B 4” (0.1 m) 18” (0.45 m) 8’ (2.4m) - CANADA... -
Page 7: Installation On High Ceilings
INSTALLATION ON HIGH CEILINGS When installing the heater on high ceilings, it is highly recommended to suspend the heater to ensure optimal heating performance. In outdoor environments it is not recommended to mount the bottom of the heater above 8’ in CANADA and 7’ in USA. This section will help the installer select an optimal extension bracket to ensure the heater is installed at the optimal height. -
Page 8: Electrical Installation
ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3. Use a proper electrical connection box. 4. Supply voltage and frequency must correspond to the electrical rating indicated on unit’s information plate. -
Page 9: Ceiling Mounted Installation
Heater should be hung using rigid mounting brackets, the unit must not be able to swing in any direction under applied load from wind or WARNING persons. The unit must be installed using the supplied brackets or Aura Shadow extension brackets. Secure the heater to the mounting brackets using nuts and washers provided. -
Page 10: Adjusting Directional Positioning
ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3. -
Page 11: Maintenance
3 - MAINTENANCE WARNINGS 1. Allow the heater and the emitter to cool down before handling. Installation and maintenance must be performed by a qualified technician. Turn off the power before beginning maintenance. Do not attempt to service or repair the unit while it is running. 5. -
Page 12: Limited Express Warranty
IMITED XPRESS ARRANTY Limited Express Warranty AURA® Infrared Heaters RESIDENTIAL INSTALLATION/USE: purchase. The consumer must retain a receipted bill of sale as proof of LIMITED ONE (1) YEAR PARTS WARRANTY warranty period. Without this proof, the express warranty begins on the Inforesight Consumer Products Inc.
