INSTALLATION, OPERATION AND MAINTENANCE MANUAL
MODELS
AD30240 (B / W /SS)
ADGLASS30240 (B / W)
AD15120 (B / W/ SS)
ADGLASS15120 (B / W)
During operation, always ensure combustible materials are kept at a safe distance from the heater
body and from the emitted radiant energy. This heater is not intended for use in hazardous areas where
flammable vapours, gases, liquids or other combustibles are present. Failure to do so can result in
personal injury/or property damage.
FOR OUTDOOR RESIDENTIAL AND INDOOR OR OUTDOOR COMMERCIAL USE
INFORESIGHT CONSUMER PRODUCTS INC. * 125 TRADERS BLVD #4 * MISSISSAUGA, ONTARIO * 905-568-7655
Aura DÉCOR Series Infrared electric heater
VOLTAGE
240 /208
240 /208
120
120
FIRE/EXPLOSION HAZARD WARNING
NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES
TOTAL POWER (W)
3000/2250
3000/2250
1500
1500
CURRENT(AMPS)
12.5 / 10.8
12.5 / 10.8
12.5
12.5
1
Advertisement
Related Manuals for Aura DECOR Series
Summary of Contents for Aura DECOR Series
- Page 1 INSTALLATION, OPERATION AND MAINTENANCE MANUAL Aura DÉCOR Series Infrared electric heater MODELS VOLTAGE TOTAL POWER (W) CURRENT(AMPS) AD30240 (B / W /SS) 240 /208 3000/2250 12.5 / 10.8 ADGLASS30240 (B / W) 240 /208 3000/2250 12.5 / 10.8 AD15120 (B / W/ SS) 1500 12.5...
- Page 2 This Product manual covers: Heaters rated 120V, 1500W AD15120 ADGLASS15120 Heaters rated 240-208V, 3000W (2250W at 208V) AD30240 ADGLASS30240...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 - SAFETY ................................4 2 - INSTALLATION INSTRUCTIONS .......................... 6 3 - OPERATING INSTRUCTIONS ..........................11 3.1.1 Operation of the Remote Control ....................11 4 - MAINTENANCE ..............................12 5 - grounding instructions............................. 15 6 - Limited Express Warranty..........................17 WARNINGS THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, FAILURE TO FOLLOW WARNINGS AND INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, OR INJURY. -
Page 4: Safety
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. This heater must be used strictly according to these instructions. 1 - SAFETY WARNINGS WARNING: FIRE OR EXPLOSTION HAZARD... - Page 5 Ensure the emitter is state and national electric codes (NEC). not cracked or chipped visually. Contact an authorized Aura dealer for support. • This product is not suitable for indoor residential use.
-
Page 6: Installation Instructions
AURA infrared heaters produce radiant heat that warms people and objects, rather than the air around them. The heater can be wall or ceiling mounted and includes brackets which allow the user to direct the infrared heat where desired. - Page 7 ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3. Use a proper electrical connection box. 4. Supply voltage and frequency must correspond to the electrical rating indicated on unit’s information plate 3000W heaters must be used on 208 or 240V.
- Page 8 WALL-MOUNTED INSTALLATION THE HEATERS MUST BE INSTALLED WITH THE MOUNTING BRACKETS PROVIDED IN THE BOX. 1. Take the heater out of the box and remove all The bracket should be installed with the bracket protective foam inserts and packaging. mounting holes facing upwards. NOTE: Wall bolts or anchors are not supplied.
- Page 9 CEILING MOUNTED INSTALLATION Heater should be hung using rigid mounting brackets, the unit must not be able to swing in any direction under applied load from wind or persons. It is highly recommended that users install the heater with the WARNING ceiling mounting hardware provided.
- Page 10 ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3.
-
Page 11: Operating Instructions
1. Use 2 pieces AAA, 1.5V batteries (not included) in the remote control. Remove the batteries when not in use for an extended period of time to increase battery life. 2. Contact your local authorized Aura Dealer for remote replacement. 3. The remote-control function may not work if there is a barrier between the remote control and heater. -
Page 12: Maintenance
4 - MAINTENANCE WARNINGS 1. Allow the heater and the emitter to cool down before handling. Installation and maintenance must be performed by a qualified technician. Turn off the power before beginning maintenance. Do not attempt to service or repair the unit while it is running. 5. - Page 13 REPLACING THE EMITTER Contact your distributor for the correct replacement emitter, providing the model number and rating from the rating label. Using an incorrect replacement emitter can cause the heater to fail. Notice: Read through the Emitter replacement procedure below before beginning the replacement. For easier replacement, remove the heater from the wall or ceiling.
- Page 14 9. Bend the metal tabs to remove the small reflector the emitter surface. Fingerprints on the emitter shield sheet metal parts. Hold on to these pieces. surface can lead to surface hot spots and reduced This will allow you to slide the emitter into a bigger emitter life.
-
Page 15: Grounding Instructions
5 - GROUNDING INSTRUCTIONS 3000W MODELS FOR USE ON 240 OR 208V Connection to GFCI protected outlet is recommended For outdoor, exposed environments and/or as required by local, state and National Electrical Code (NEC) requirements. WARNING FAILURE TO USE A GFCI PROTECTED OUTLET COULD RESULT IN FIRE OR ELECTRIC SHOCK! This heater is for use on 240 Volts. - Page 16 1500W MODELS FOR USE ON 120V Connection to GFCI protected outlet is recommended For outdoor, exposed environments and/or as required by local, state and National Electrical Code (NEC) requirements. WARNING FAILURE TO USE A GFCI PROTECTED OUTLET COULD RESULT IN FIRE OR ELECTRIC SHOCK! This heater is for use on 120-volt circuits.
-
Page 17: Limited Express Warranty
6 - LIMITED EXPRESS WARRANTY Limited Express Warranty AURA® Infrared Heaters RESIDENTIAL INSTALLATION/USE: period of this warranty, Inforesight Consumer Products Inc. LIMITED ONE (1) YEAR PARTS WARRANTY replacement parts shall be used; any warranty on the Inforesight Consumer Products Inc. warrants all parts of the...
