Please note that this is an exemplary representation and listing of the common connections of a
PC system. For the product specific connections and their properties, please use the manual of
the mainboard manufacturer.
1. PS/2
If you have a keyboard or mouse with a PS/2 connector, please use this connector for your
input device.
2. USB
You connect your USB devices to these ports. There are two types of connectors: USB type A
(2.a) and USB type C (2.b)
3. Graphics
Please note: If you have a PC system with a dedicated graphics card, please use only the graph-
ics card ports (3.1). The integrated graphic outputs of the mainboard (3.2) are deactivated in
this case. Different types of connectors are available for the graphic output. Please use the
appropriate output port for your display device or connection cable.
(3.a) VGA Port, (3.b) DVI Port, (3.c) HDMI Port, (3.d) DisplayPort
4. Network (LAN)
To establish a wired connection to a router, switch or modem, please use this connection with a
suitable network cable (RJ45 plug).
5. Audio
Please use these connections for input and output of audio signals. As standard 3.5 mm jack
sockets (5.1) are provided. For optical audio signals some mainboards offer an SP/DIF output
(5.2).
Please refer to the enclosed manual of the mainboard manufacturer for the product-specific
assignment of the audio sockets, e.g. for the connection of surround sound systems.
6. WLAN
If your system is equipped with a WLAN card, please mount the enclosed WiFi antennas on the
ports of the WLAN card to enable a stable wireless connection.
7. Power supply
Set the PC up near a plug socket. Only power the PC from an earthed household wall socket. If
you are using an extension cable, please ensure that this conforms to VDE-GS standards.
8. Main switch
The main switch is located on the PC power supply unit and switches it on.
9. CardReader
If your PC system is equipped with a card reader, you can use your memory cards at its ports.
For more information on the specifications of your card reader, refer to the enclosed manual or
the manufacturer's website.
10. Power
Start up the PC by pressing the Power-button.
18
