- Page 1 LogTag Recorders USRID-16W W1 & W2 WHO Version Single-use USB PDF Electronic Shipping Indicator Product User Guide Document Release Version: 1.0 Published 27. January 2021 Copyright © 2004-2021, LogTag Recorders 1.800.561.8187 information@itm.com www. .com...
-
Page 2: Table Of Contents
USRID-16W User Guide Contents Introduction Required Equipment What's in the Box Features Case Buttons Display Software Requirements Configuring the USRID-16W for logging Standard Configuration Options Alarms Advanced Configuration Settings File Settings Finalizing the configuration USRID-16W Start Options Display Overview Operating the Logger After the Logger is configured Starting the Logger During Recording... - Page 3 Keep out of the reach of children. Liability LogTag Recorders’ standard warranty terms apply. A copy can be requested by emailing . In addition, LogTag Recorders shall not be held liable ...
- Page 4 Text in this font refers to option settings, dialogue boxes or actions to be taken in ® LogTag Analyzer. Text describes features of the product. in this font This text describes certain aspects of the product, where incorrect use of a feature may lead to inadvertent loss of data.
-
Page 5: Introduction
What's in the Box USRID-16W Waterproof backing card 6-language instruction booklet Features The USRID-16W Single-use USB PDF temperature loggers feature the familiar LogTag case layout with an additional USB plug at the bottom. 1.800.561.8187 information@itm.com www. .com... -
Page 6: Case
Features USRID-16W User Guide Case Mounting lug for secure fastening of logger to fixtures USB plug with protective cap - shields USB connector from moisture and dirt Temperature sensor located inside case Durable polycarbonate case, IP65 Buttons ... - Page 7 Features USRID-16W User Guide The PDF can be shown in several different languages: English French German Russian Spanish The default ex-factory language is English. You can select which language to use during configuration in the File Settings tab.
-
Page 8: Software Requirements
Analyzer without accessing the logger‘s on-board files. 1.800.561.8187 information@itm.com Depending on the configuration, the USRID-16W may produce all, some or none of the files. www. .com PDF files generated by any USB logger can be opened directly in LogTag Analyzer. ®... -
Page 9: Configuring The Usrid-16W For Logging
Remove the protective cap from the logger's USB connector, plug it into a USB socket on your computer and wait for the drivers to be installed ® From the menu click LogTag - Configure; LogTag Analyzer will display the configuration options for connected loggers. Standard Configuration Options The only parameter in the standard configuration options you are permitted to customize is the Description. -
Page 10: Alarms
Configuring the USRID-16W for USRID-16W User Guide logging Alarms Configuring alarms for WHO PQS qualified USRID-16W1 and USRID-16W2 models is not permitted. The alarm trigger requirements are set out in the WHO/PQS/E006/TR07 PQS performance specification for Electronic Shipping Indicators. Each indicator is configured with 3 different alarm trigger conditions for temperature. -
Page 11: Advanced Configuration Settings
Please note that the USRID-16W1 and USRID-16W2 models can only display temperatures in °C, are always reporting times in UTC and always produce a PDF file. ® Figure 1: USRID-16W File settings screen in LogTag Analyzer 3 These parameters influence the appearance of all files: ... -
Page 12: Finalizing The Configuration
For detailed information about each parameter please read the section about Configuring a ® ® LogTag for logging in LogTag Analyzer’s User Guide or press F1 for help. The PDF file can not only be viewed in a PDF viewer, but can also be opened with ®... -
Page 13: Display Overview
Display Overview USRID-16W User Guide Display Overview ALARM/OK indicator symbol is shown as soon as the USRID-16W has registered an alarm event. While there are no alarms, or if a previous alarm has been cleared, the symbol is shown. Recording indicators The recording indicators show what the USRID-16W is currently recording. - Page 14 Display Overview USRID-16W User Guide Figure 2: Alarm arrows pointing to the alarm labels Battery Low The battery low symbol will appear if the USRID-16W's battery is low. If the symbol is not shown while the display is turned on, the battery is still OK. 1.800.561.8187 information@itm.com www.
-
Page 15: Operating The Logger
Operating the Logger USRID-16W User Guide Operating the Logger The following sections show how to operate the product, and what information you can expect to see on the display. After the Logger is configured The USRID-16W is pre-configured for a push button start, and the word is shown. -
Page 16: During Recording
Operating the Logger USRID-16W User Guide The delay time is shown in hours and minutes. The time counts down and the USRID-16W starts recording when it reaches 0 00. The logger will not start if you release the button while the symbol is still flashing;... -
Page 17: Stopping The Usrid-16W
Operating the Logger USRID-16W User Guide Pressing either button briefly will switch the display on, and show , indicating the READY product is ready to start. It will show the Battery Empty symbol ( ), if the battery is low. As soon as the device has been started, the display remains permanently switched on, even when the device has finished recording temperatures. - Page 18 Operating the Logger USRID-16W User Guide If the button is released while is still blinkingon, or you wait until STOPPED STOPPED disappears, the display shows again, and the logger continues to record data. In this case, an inspection mark will be recorded in the data against the next temperature reading. Logger has stopped Once the logger has stopped, the display will show: ...
-
Page 19: Reviewing Min/Max Values And Alarms
Operating the Logger USRID-16W User Guide Reviewing Min/Max values and Alarms Once the logger has stopped and is not plugged into a USB port, you can review the recorded minimum and maximum temperature readings and alarm trigger events using the button. -
Page 20: Plugging The Usrid-16W Into A Usb Port
Operating the Logger USRID-16W User Guide Pressing for a second time will show the STOP /Review lowest recorded temperature during the trip, indicated TRIP MIN The example screen shows that the minimum temperature recorded was -1.5 °C. Pressing again will show up to three more screens, one for each of the STOP /Review configured alarm trigger conditions. - Page 21 What happens on your computer depends on the operating system of the computer, the ® settings made during configuration and whether or not LogTag Analyzer is running. Microsoft Windows Up to four drivers will now be installed, depending on the USRID-16W's configuration.
-
Page 22: Accessing The Files
For PDF files you need Adobe Acrobat Reader or a similar PDF viewer. ® To open the LTD file you need to install the free LogTag Analyzer software. CSV files can be opened with a text editor, or imported into a spreadsheet program ®... -
Page 23: Interpreting The Data
Interpreting the Data USRID-16W User Guide Interpreting the Data Figure 4: Sample report page Data Evaluation - Report Alarm Status This shows at a glance if the USRID-16W recorded alarm conditions during the trip (showing a red ) or if no alarms were recorded (showing a green Recorded Data Overview This section shows at what time the logger started to record data, when it finished, how many readings were recorded and how long that took. - Page 24 Interpreting the Data USRID-16W User Guide ® º symbol will be shown, if the USRID-16W was downloaded with LogTag Analyzer. • symbol will be shown if an inspection mark was placed with the START /Mark button. • ...
- Page 25 Interpreting the Data USRID-16W User Guide Direction (whether it is an upper or lower alarm) Alarm threshold temperature value Any delay value for consecutive or accumulative alarms The total time above or below a threshold How often an alarm occurred ...
-
Page 26: Data Evaluation - Data List
Interpreting the Data USRID-16W User Guide Data Evaluation - Data List Figure 5: Sample Data List File Information This section shows general information about the PDF file, such as generation time, date and time formats used in the chart and the data list as well as the file name, which is compiled from information about the data it contains: LogTag_[serial_number]_[trip number]_[file creation date]_file creation time]_[OK or ALM].pdf Other files that may be generated have the extensions *.csv and *.ltd. - Page 27 In the data list, each entry may be marked with one or more of the following symbols: ® A + symbol will be shown, if the USRID-16W was downloaded with LogTag Analyzer. A * symbol will be shown if an inspection mark was placed with the...
-
Page 28: Technical Specifications
Technical Specifications USRID-16W User Guide Technical Specifications Model Number USRID-16W1, USRID-16W2 Temperature sensor measurement range -30 °C to +60 °C (-22 °F to +140 °F) Operating temperature range -30 °C to +70 °C (-22 °F to +158 °F) Ambient temperature range during transport -30 ... - Page 29 PDF report. Download time Typically less than 10 seconds from time of insertion to availability of LTD file in ® LogTag Analyzer (if configured) ® LogTag Analyzer version 3.1r10 or later to configure and download Software requirements ...
