LPX30WB VL-Bus System Board Manual Document Number: 06-00226-01, Rev. 3A February 1995 221 Warren Ave., Fremont, CA 94539-7085...
Page 2
Micronics assumes no responsibility for any inaccuracies that may be contained in this document. Micronics makes no commitments to update or to keep the information in this manual at a current level when changes are made to the product.
Page 3
Micronics Quick Installation We know many experienced people prefer to read as little of the documenta- tion as possible. If this sounds like you, here’s the short form: Ground yourself to prevent damaging static discharge, then remove the LPX30WB from its packaging.
Page 4
Turn the computer on and press the <Ctrl>, <Alt>, and <Esc> keys simultaneously after you see the screen below: Set the time and date. Adjust the BIOS settings to match what is installed in your system. If installing an IDE drive, select the IDE device you wish to configure.
Page 5
Contents Introduction ............... 1-1 Features ..................1-2 Configuring the LPX30WB ..........2-1 Static Electricity ............... 2-1 Office Environment ..............2-1 LPX30WB Components ............2-2 Jumper Settings................. 2-3 Installing the LPX30WB, System Memory, CPUs and Peripherals ................. 3-1 Installation of the LPX30WB ........... 3-2 Tools Required ..................
Page 6
Setting the CMOS Parameters ..........4-3 Setting the CMOS Main Screen ............. 4-4 System Time and Date................4-4 Diskette Drive A or B ................4-4 Hard-Disk Drive 1-4 (IDE Drives Only)..........4-4 Base Memory and Extended Memory ............ 4-4 Video Card....................4-4 System Speed ..................
Page 7
Utilities Summary ................6-14 Driver Installation ..............6-18 Lotus 1-2-3, versions 2.1 and 2.2 ............6-18 Symphony 2.x ..................6-19 GEM Desktop 3.xx ................6-20 Ventura Publisher ................. 6-20 WordPerfect ................6-21 WordPerfect 5.1 ..................6-21 WordPerfect 6.0 ..................6-22 Microsoft Word for DOS ............
