- Page 1 M54Hi-Plus PCI/ISA System Board Manual Document Number: 06-00253-03, Rev. 1B April 1996 221 Warren Ave., Fremont, CA 94539-7085...
- Page 2 Micronics assumes no responsibility for any inaccuracies that may be contained in this document. Micronics makes no commitments to update or to keep the information in this manual at a current level when changes are made to the product.
- Page 3 1. Make backup copies of your installation and configuration diskettes. 2. Ground yourself to prevent damaging static discharge, then remove the M54Hi-Plus from its packaging. 3. Configure and verify the system board’s jumper settings. (See Jumper Settings in Chapter 2) 4.
- Page 4 9. Set the time and date. Adjust the BIOS settings to match your configuration. If installing an IDE drive, select the IDE device you wish to configure. Press <Enter> with Autotype Fixed Disk selected and the BIOS will automatically configure the drive for you (Chapter 4). 10.
-
Page 5: Table Of Contents
Software Compatibility ............. Configuring the M54Hi-Plus ..........Static Electricity ................ Office Environment ..............M54Hi-Plus Components............Jumper Settings ................. Installing the M54Hi-Plus, System Memory, CPUs and Peripherals ................. Installation of the M54Hi-Plus ..........Tools Required ..................Equipment Required ................System Memory ................ - Page 6 The BIOS Setup Utility............Configuration ................Initial Boot Up ................Setup ..................Running the Setup Procedure ........... Setting the Main Screen ............System Time and Date ................Diskette A or B ..................IDE Adapters (Hard Disk Setup) ............Video System ..................Cache Video BIOS .................
- Page 7 Installing a CD-ROM Drive and the Sound Controller Driv- ers ..................About Device Drivers ............... Installing a CD-ROM Drive ............Installing the Sound Controller Drivers ........POST Messages..............Beep and POST Codes ............. Hard Disk Drive Types ............Specifications ..............Environmental Specifications ............D-2 Temperature Range ................
- Page 8 List of Figures Figure 2-1: M54Hi-Plus Components ............Figure 3-1: Installing a 72-Pin SIMM ............Figure 3-2: Installing a Cache Module ............Figure 3-3: Installing the Sound Riser Card ..........Figure 3-4: Connecting External Devices to the Sound Controller ....
-
Page 9: Introduction
Out) memory support, pipelined burst cache support, 16-bit sound, infrared support, the PCI bus, and Phoenix 4.0x Plug and Play BIOS. The M54Hi-Plus also has on-board support for two floppy drives, a bi- directional parallel port, and two high speed serial ports. -
Page 10: Features
16-bit sound controller based on the Creative Labs Vibra 16S chipset. Built-in infrared support. Upgradeable Flash Phoenix BIOS. Software Compatibility The M54Hi-Plus system board was thoroughly tested for compatibility with a variety of operating systems and environments, including: Windows, Windows 95, and Windows NT. OS/2. -
Page 11: Configuring The M54Hi-Plus
M54Hi-Plus via the solder pads surrounding one of its mounting holes. Once the M54Hi-Plus is removed from its packaging, place it on top of the antistatic bag. Carefully inspect the board for damage which may have occurred during shipment. -
Page 12: M54Hi-Plus Components
Micronics M54Hi-Plus System Board Manual M54Hi-Plus Components Figure 2-1 M54Hi-Plus System Board... -
Page 13: Jumper Settings
Jumper Settings Table 2-1: Jumper settings to select the speed of the CPU. Jumper CPU Speed 75MHz External / 50MHz Internal closed closed 90MHz External / 60MHz Internal (default) open closed 100MHz External / 66MHz Internal closed open 120MHz External / 60MHz Internal open closed 133MHz External / 66MHz Internal... -
Page 14: Table 2-5 Boot Block Selection
Micronics M54Hi-Plus System Board Manual Table 2-5 lists the jumper settings to select the BIOS boot block. Jumper Function Setting Normal (default) Reversed Table 2-5 Boot Block Selection Table 2-6 lists the jumper settings to reset the BIOS. With the computer’s power off, short Jumper W9 for about five seconds and place the jumper back in the open position. -
Page 15: Table 2-7 Case And Peripheral Connections
Jumper Settings Table 2-7 lists the jumper settings for case and peripheral connections. Jumper Function Notes Primary IDE Connector Primary Secondary IDE Connector Secondary Floppy Connector Parallel Port Connector Can be disabled at the CMOS configuration screen. Serial Port 1(Com1) Can be disabled at the CMOS configuration screen. -
Page 16: Installing The M54Hi-Plus, System Memory, Cpus And Peripherals
Installing System Memory and Add-On Peripherals Installing the M54Hi-Plus, System Memory, CPUs and Peripherals This section explains how to install the M54Hi-Plus system board, SIMMs, CPUs, and peripherals. Warning: Before installing or removing any peripherals or components, make sure you have a clear work space and adhere to all anti-static precautions described on page 2-1. -
Page 17: Installation Of The M54Hi-Plus
Micronics M54Hi-Plus System Board Manual Installation of the M54Hi-Plus The installation of the M54Hi-Plus system board depends on the type of case you use. The M54Hi-Plus is an integrated baby AT size system board and may be installed into most cases. -
Page 18: System Memory
System memory devices, commonly known as SIMMs (Single Inline Memory Modules), are necessary to operate the M54Hi-Plus system board. The M54Hi-Plus has four SIMM sockets and may be upgraded to 128 Megabytes of RAM. This section will explain the type of SIMMs supported, list the rules of adding memory to the M54Hi-Plus, give some examples of common memory configurations, and show how to physically install the new SIMMs. -
Page 19: Common Memory Configurations
Micronics M54Hi-Plus System Board Manual Common Memory Configurations The following table (Table 3-1) lists the most common memory configura- tions. The M54Hi-Plus will accept any combination of SIMMs as long as the rules in the previous section are followed. Memory... -
Page 20: Installing The Simms
Installing System Memory and Add-On Peripherals Installing the SIMMs To install the SIMMs, locate the memory banks on the system board and perform the following steps: Hold the SIMM so the notched edge is aligned with the notch on the SIMM socket (Figure 3-1). Insert the SIMM at a 45 degree angle. -
Page 21: Installing A Cpu
Micronics M54Hi-Plus System Board Manual Installing a CPU The M54Hi-Plus is designed to a variety of Pentium processors. Follow the steps below to install a processor: Turn off the computer and remove its cover. Locate the ZIF socket illustrated in Figure 2-1. -
Page 22: Installing A Cache Module
Installing a Cache Module In addition to the 16K of internal (L1) cache built into the Pentium proces- sors, the M54Hi-Plus also supports external (L2) cache. The M54Hi-Plus supports pipelined burst cache and asynchronous cache (256K or 512K). To install a cache module, follow these instructions: 1. -
Page 23: Installing The Sound Riser Card
Micronics M54Hi-Plus System Board Manual Installing the Sound Riser Card To install the Sound Riser Card, follow the instructions below: 1. Turn the computer off and remove the chassis cover. 2. Remove the slot cover closest to the sound connector (far left hand side of the system board). -
Page 24: Connecting Devices To The Sound Controller
Installing System Memory and Add-On Peripherals Connecting Devices to the Sound Controller In order to take advantage of the on-board sound controller, you may connect external devices to the M54Hi-Plus. Figure 3-4 Connecting External Devices to the Sound Controller External Speakers You may connect 4 or 8 ohm external speakers or headphones to the audio controller. -
Page 25: Joystick
Micronics M54Hi-Plus System Board Manual Joystick Plug the joystick into the 15-pin connector on the back of the M54Hi-Plus. MIDI If you purchased the optional MIDI interface kit, an additional cable was included. This cable plugs into the 15-pin connector and provides MIDI IN and MIDI OUT connections, in addition to a joystick connection. -
Page 26: Installing A Pci Peripheral Card
Installing System Memory and Add-On Peripherals Installing a PCI Peripheral Card Micronics PCI slots accommodate all PCI peripherals which adhere to the PCI 2.0 specifications. Complete the following steps to install a PCI card: 1. Turn the computer system off and remove its cover. -
Page 27: Installing An Isa Peripheral Card
Micronics M54Hi-Plus System Board Manual Installing an ISA Peripheral Card Micronics ISA slots accommodate all standard ISA peripherals. Complete the following steps to install an ISA card: 1. Turn the computer system off and remove its cover. 2. Choose an unused ISA slot and remove the slot cover. -
Page 28: The Bios Setup Utility
Initial Boot Up Power up the M54Hi-Plus. If the system does not properly boot, check all your cables and peripherals for bad connections. You may also get beep codes or error messages. If this occurs, consult Appendices A and/or B for a guide to possible solutions. -
Page 29: Setup
Micronics M54Hi-Plus System Board Manual Setup The Setup program is used to configure the computer’s BIOS (Basic Input/ Output System). The computer’s BIOS is responsible for configuring the system board and providing hardware information to the operating system. In order for the computer to run properly, run the Setup procedure after first installing the system board and whenever you make a hardware change to the system. -
Page 30: Running The Setup Procedure
The BIOS Setup Utility Running the Setup Procedure The M54Hi-Plus system board has four primary CMOS configuration screens: the Main Screen (Figure 4-2), the Advanced Screen (Figure 4-5), the Security Screen (Figure 4-10), and the Exit Screen (Figure 4-10). To toggle between the screens, press the right arrow <→>... -
Page 31: Diskette A Or B
Micronics M54Hi-Plus System Board Manual up and down arrows<↑/↓> to highlight the System Date and follow the same procedure used to set the time. Diskette A or B To configure a floppy drive added to or removed from your computer, use the up and down arrow keys <↑/↓>... - Page 32 The BIOS Setup Utility Do not adjust the rest of the settings unless absolutely necessary. The BIOS automatically enters the optimal settings. Type This category selects the drive type installed in the system. The options are 1-39, User, and none. It is doubtful you will find your drive in 1-39. If Autotype Fixed Disk does not find your drive’s parameters, fill this information in manually under the User category.
-
Page 33: Video System
Micronics M54Hi-Plus System Board Manual Video System This sets the type of video board installed into the system. You may choose EGA/VGA (default), CGA 80x25, MONO, or Not Installed. Cache Video BIOS The Cache Video BIOS category allows you to Shadow or Shadow & Cache the video BIOS. -
Page 34: Cache
The BIOS Setup Utility Boot Sequence This category selects the order the system searches for a boot disk and may be set for: A: then C: C: then A: C: only SETUP Prompt When enabled, this category allows the system to display the “Press <F2> to enter SETUP”... -
Page 35: Setting The Advanced Screen
Micronics M54Hi-Plus System Board Manual Setting the Advanced Screen To move to the Advanced Screen, use the left and right arrow keys <←/→> keys until you see the screen below (Figure 4-5). Figure 4-5 Advanced Screen... -
Page 36: Integrated Peripherals Submenu
The BIOS Setup Utility Integrated Peripherals Submenu The Integrated Peripherals submenu (Figure 4-6) allows you to individually enable or modify the drives, I/O ports, and other settings. Use the up and down arrow keys <↑/↓> to select a category and the plus and minus keys <+/->... -
Page 37: Plug And Play O/S
Micronics M54Hi-Plus System Board Manual Diskette Controller The floppy disk controller may be enabled or disabled. Integrated PCI IDE The PCI IDE controller may be set for Primary (up to two hard disks), Both (up to four hard disks), or it may be disabled. -
Page 38: Security Screen
The BIOS Setup Utility Security Screen The Security Screen (Figure 4-7) controls access to the computer. The security screen allows for settings of two passwords. The Supervisor Pass- word allows access to the system and Setup. The User Password allows access to the system, but not to all Setup features. -
Page 39: Set User Password
Micronics M54Hi-Plus System Board Manual Figure 4-8 Supervisor Password Submenu Type the password and press the <Enter> key. Retype the password and press the <Enter> key again. Write down the password somewhere safe so it will not be forgotten. The password may be disabled by setting the new password to nothing (pressing the <Enter>... -
Page 40: Diskette Access
The BIOS Setup Utility Diskette Access This category allows floppy disk access with an option of the supervisor or user. Selecting Supervisor gives floppy disk access to the supervisor only. Selecting User (default) gives floppy disk access to both the user and the supervisor. -
Page 41: Apm
Micronics M54Hi-Plus System Board Manual When enabled the power management features are active. The default setting is Disabled. If you enable this category, you must also set the other power management options below. Power Management Mode This category may be set for Maximum power savings, Medium power savings, Minimum power savings, Customized, or Disabled (default). -
Page 42: Crt Standby
The BIOS Setup Utility CRT Standby Selecting Enabled powers down the display while the system is in power saving mode. The default setting is disabled. Before making changes, “Customized” must be selected in the Power Management Mode category. Standby Timer Reset Events Keyboard Setting this option to Enabled causes the standby timer to reset every time any keyboard activity occurs. -
Page 43: Exit Screen
Micronics M54Hi-Plus System Board Manual Exit Screen After you complete configuring the BIOS, select the Exit Screen (Figure 4- 10). Figure 4-10 Exit Screen Choose “Save Changes and Exit” and reboot the computer. The computer is ready for use. 4-16... -
Page 44: Installing A Cd-Rom Drive And The Sound Controller Drivers
Sound Controller Drivers This chapter explains how to install a CD-ROM drive and the sound drivers necessary to operate the sound controller on the M54Hi-Plus. Prior to installing any drivers, follow the instructions in Chapter 3 on how to install the sound riser card and how to connect devices to the sound controller. -
Page 45: Installing A Cd-Rom Drive
Micronics M54Hi-Plus System Board Manual Installing a CD-ROM Drive Micronics recommends the installation of an IDE CD-ROM. If you are installing a CD-ROM drive these instructions will help you, but also refer to the documentation which accompanied your CD-ROM drive. Before starting the setup and installation, make sure your computer is off and the power cord is disconnected from the wall outlet. -
Page 46: Installing The Sound Controller Drivers
Installing the Sound Drivers Installing the Sound Controller Drivers If you are installing a CD-ROM drive, it is recommended you install it before setting up the sound controller. See Installing a CD-ROM Drive on the previous page. 1. Follow the instructions in Chapter 3 on installing the sound riser card and connecting devices. -
Page 47: Post Messages
POST Messages POST Messages The following table lists the Power On Self Test (POST) messages, possible causes, and solutions. Message Possible Cause Solution DISKETTE DRIVE A Drive A failed or is Check Setup and cable FAILURE missing. connections. DISKETTE DRIVE B Drive B failed or is Check Setup and cable FAILURE... - Page 48 Micronics M54Hi-Plus System Board Manual Message Possible Cause Solution MONITOR TYPE Monitor type not Run Setup and enter DOES NOT MATCH correctly identified in correct monitor type. CMOS Setup. OPERATING Operating system Check Setup to see if SYSTEM NOT cannot be located on...
-
Page 49: Beep And Post Codes
Beep codes are a series of beeps sent through the speaker which indicate a problem during the Power On Self Test (POST). If text appears on the video screen, the M54Hi-Plus has completed POST; any other tone from the speaker indicates something other than a POST error. - Page 50 Micronics M54Hi-Plus System Board Manual Code Beeps POST Routine Description Verify Real Mode. Get CPU type. Initialize system hardware. Initialize chipset registers with initial POST values. Get in POST Reg. Initialize CPU registers. Initialize cache initial POST values. Initialize I/O.
- Page 51 Beep and POST Codes Code Beeps POST Routine Description Initialize all video adapters in system. Shadow video BIOS ROM. Display copyright notice. Display CPU type and speed. Initialize EISA board. Test keyboard. Set key click if enabled. Enable keyboard. 2-2-3-1 Test for unexpected interrupts.
- Page 52 Micronics M54Hi-Plus System Board Manual Code Beeps POST Routine Description Set up Power Management. Enable hardware interrupts. Set time of day. Check key lock. Initialize typematic rate. Erase F2 prompt. Scan for F2 keystroke. Enter SETUP. Clear in-POST flag. Check for errors.
-
Page 53: Hard Disk Drive Types
Hard Disk Drive Types Hard Disk Drive Types The following table lists the hard disk types supported by M54Hi-Plus. Type Cylinders Heads Write Sectors Size Precomp none none none none none none none none 1024 none none none 1218 none... - Page 54 Micronics M54Hi-Plus System Board Manual Type Cylinders Heads Write Sectors Size Precomp none none 1024 none 1024 none 1024 none none...
-
Page 55: Specifications
Specifications Specifications Processor 75MHz, 90MHz, 100MHz, 120MHz, 133MHz, 150MHz, or 166MHz Pentium processors. Chipset Intel 430FX PCIset SMC FDC37C932 Ultra I/O controller. CPU Clock Select Frequency synthesizer chip. Jumper selectable CPU speed. Form Factor Baby AT footprint (8.5" x 13"). Expansion Three ISA slots and three PCI slots. -
Page 56: Environmental Specifications
Mode 4 support. Multiple sector transfer support. LBA support. Environmental Specifications The environment in which the M54Hi-Plus is located is critical. Micronics recommends the following environmental specifications: Temperature Range Operating: 50 to 104 degrees Fahrenheit (10 to 40 degrees Celsius). -
Page 57: Battery Disposal
Specifications Battery Disposal Warning: DO NOT: open battery; dispose of in fire; recharge; put in backwards, mix with used or other battery types. May explode or leak and cause personal injury. -
Page 58: Fcc Warning Statement
Consult your dealer or an experienced radio/TV technician for help. To meet FCC requirements, shielded cables are required. Note: Changes or modifications not expressly approved by Micronics could void the user’s authority to operate the equipment. -
Page 59: Declaration Of Conformity
Micronics M54Hi-Plus System Board Manual Declaration of Conformity Application of Council Directives 89/336/EEC and 72/23/EEC. Standards to which the conformity is declared: EN55022 EN50082-1 EN 60950 Manufacturer's Name: Micronics Computers, Inc. Manufacturers Address: 221 Warren Avenue Fremont, California 94539 Tel: (510) 651-2300... - Page 60 Application of Council Directives 89/336/EEC and 72/23/EEC. Standards to which the conformity is declared: EN55022 EN50082-1 EN 60950 Manufacturer's Name: Micronics Computers, Inc. Manufacturers Address: 221 Warren Avenue Fremont, California 94539 Tel: (510) 651-2300 Fax: (510) 651-5612 Type of Equipment:...
- Page 61 Micronics M54Hi-Plus System Board Manual Declaration of Conformity Application of Council Directives 89/336/EEC and 72/23/EEC. Standards to which the conformity is declared: EN55022 EN50082-1 EN 60950 Manufacturer's Name: Micronics Computers, Inc. Manufacturers Address: 221 Warren Avenue Fremont, California 94539 Tel: (510) 651-2300...
-
Page 62: Glossary
Glossary Glossary Byte - A group of adjacent bits treated as a unit. 16550 UART - A high speed chip for controlling Eight bits are typically considered one byte. Also serial ports. Although unnecessary for a mouse, it called a character. is required for modems that are 14,400 baud or faster. - Page 63 Micronics M54Hi-Plus System Board Manual EISA - An acronym for Extended Industry L1 Cache - See Internal Cache. Standard Architecture. EISA is a bus design standard which is fully backward compatible with L2 Cache - See External Cache. the ISA bus. Although it is a 32-bit bus, it only runs at 8MHz.
- Page 64 Glossary Plug and Play - A standard developed to ensure SRAM - An acronym for Static Random Access easy installation of peripherals. Theoretically, a Memory. A type of memory that can retain data newly installed card automatically configures without requiring a regular clock signal. itself and works properly without requiring Although they are faster than DRAM, they hold jumper configuration or device drivers.
-
Page 65: Limited Warranty
A receipt or copy of the invoice with the date of purchase from a Micronics reseller is required before any warranty service can be rendered. Service can be obtained by calling Micronics for a Return Merchandise Authorization (RMA) Number. -
Page 66: Non-Warranty Service
Micronics M54Hi-Plus System Board Manual Micronics will not be liable for any lost profits or any indirect, special incidental or consequential damages in connection with the product, even if Micronics has been advised of the possibility of such damages. Micronics makes no warranties or representations as to performance of products or as to service to distributor or to any person, except as set forth in Micronics;...
