Link Light

The Link Light test is used to help identify a hub or switch port.
• Press the "On/Off" button
• Connect the VDV Commander to an active network cable or port.
• Press the Network/PoE function button
• The Link Light will automatically begin to blink upon
• The Link LED above the LCD screen will flash at the same
• Use the up and down arrows to adjust the transmit
1.800.561.8187
GENERAL TESTING PROCEDURES
VDV Commander.
press the Link Light function button
entering the Link menu.
cadence as the port light.
frequency to suit the switch characteristics.
www.
to power on the
information@itm.com
.com
, then
.
