Company Confidential
Copyright 2005© Siemens AG
Service Repair Documentation
Level 2.5 - CF62, CF62R, CF63,
Release
1.0
2.0
2.1
2.2
2.3
Service Repair Documentation Level 2.5 - CF62, CF62R, CF63
Date
23.03.2004
ICM MP CCQ GRM T
12.05.2004
ICM MP CCQ GRM T
03.06.2004
ICM MP CCQ GRM T
10.12.2004
ICM MP CCQ GRM T
22.02.2005
COM MD CC GRM T
Department
Page
of
1
10
s Com
Notes to change
New document
CF63 added
Changes in procedure
VIBRA added
CF62R added
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Siemens CF62
Summary of Contents for Siemens CF62
- Page 1 ICM MP CCQ GRM T CF63 added 03.06.2004 ICM MP CCQ GRM T Changes in procedure 10.12.2004 ICM MP CCQ GRM T VIBRA added 22.02.2005 COM MD CC GRM T CF62R added Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63...
- Page 2 Level 2 repair documentation. It has to be ensured that every repaired mobile Phone is checked according to the latest released General Test Instruction document (both documents are available in the Technical Support section of the C-market). Check at least weekly C-market for updates and consider all CF62, CF63 related Customer Care Information CF62...
-
Page 3: Table Of Contents
CF62, CF62 R, CF63 board layout....................4 Connector SIM Card Reader ......................5 Connector IO Jack.........................6 Connector Board to Board......................7 Connector Battery .........................8 LED Keypad Backlight and LED Keypad Magic Ring..............9 VIBRA TRANSISTOR .........................10 Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63... -
Page 4: Cf62, Cf62 R, Cf63 Board Layout
Jigs, Tools and Working materials for all described repairs: hot air blower soldering gun tweezers flux solder LED_Keypad_Backlight LED_Keypad_Magic_Ring Connector SIM CARD READER Connector IO JACK VIBRA Transistor V211 Connector BOARD TO BOARD Connector BATTERY Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63... -
Page 5: Connector Sim Card Reader
Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components! Resolder new component afterwards. E-commerce order number: L36334-Z97-C335 Soldering temperature: 240 - 255°C IRIS Diagnose Code: 43300 Interface/SIM Cardreader/Mechanical Damage Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63... -
Page 6: Connector Io Jack
Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components! Resolder new component afterwards. E-commerce order number: L36334-Z93-C303 Soldering temperature: 240 - 255°C IRIS Diagnose Code: 46100 Interface/Charging Connector/Mechanical Damage 47300 Interface/Data Interface/Mechanical Damage 4B100 Interface/Headset Connector/Mechanical Damage Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63... -
Page 7: Connector Board To Board
Resolder new component afterwards. E-commerce order number: L36334-Z97-C341 Soldering temperature: 240 - 255°C IRIS Diagnose Code: 2A100 Display/Outer(Claimshell)/Performance 2A100 Display/Outer(Claimshell)/ Background Illumination 72110 Acoustics/Receiving/Earcap/No Function 72170 Acoustics/Receiving/Earcap/Low Voice Level 75100 Acoustics/Vibra/No Function Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63... -
Page 8: Connector Battery
Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components! Resolder new component afterwards. E-commerce order number: L36334-Z97-C336 Soldering temperature: 240 - 255°C IRIS Diagnose Code: 13000 Battery/Mechanical Damage Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63... -
Page 9: Led Keypad Backlight And Led Keypad Magic Ring
Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components! Resolder new component afterwards. E-commerce order number: CF62/CF63: L36840-L2055-D670 CF62R: L36197-F5005-F782 Soldering temperature: 240 - 255°C IRIS Diagnose Code: 36000 Keys/Illumination Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63... -
Page 10: Vibra Transistor
Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components! Resolder new component afterwards. E-commerce order number: L36810-C6144-D670 Soldering temperature: 240 - 255°C IRIS Diagnose Code: 75400 Acoustics / Vibra / Electrical Damage Page Service Repair Documentation Level 2.5 - CF62, CF62R, CF63...
