Draytek VigorPro 5300 User Manual page 153

My WAN IP
Remote Gateway IP
Remote Network IP/
Remote Network Mask
More
RIP Direction
From first subnet to
remote network, you
VigorPro5300 Series User's Guide
Callback number-The option is for extra security. Once
enabled, the router will ONLY call back to the specified
Callback Number.
Callback budget- By default, the callback function has
limitation of callback period. Once the callback budget is
exhausted, the function will be disabled automatically.
Callback Budget (Unit: minutes)- Specify the time budget
for the dial-in user. The budget will be decreased
automatically per callback connection. The default value 0
means no limitation of callback period.
This field is only applicable when you select ISDN, PPTP or
L2TP with or without IPSec policy above. The default value is
0.0.0.0, which means the Vigor router will get a PPP IP
address from the remote router during the IPCP negotiation
phase. If the PPP IP address is fixed by remote side, specify
the fixed IP address here. Do not change the default value if
you do not select ISDN, PPTP or L2TP.
This field is only applicable when you select ISDN, PPTP or
L2TP with or without IPSec policy above. The default value is
0.0.0.0, which means the Vigor router will get a remote
Gateway PPP IP address from the remote router during the
IPCP negotiation phase. If the PPP IP address is fixed by
remote side, specify the fixed IP address here. Do not change
the default value if you do not select ISDN, PPTP or L2TP.
Add a static route to direct all traffic destined to this Remote
Network IP Address/Remote Network Mask through the VPN
connection. For IPSec, this is the destination clients IDs of
phase 2 quick mode.
Add a static route to direct all traffic destined to more Remote
Network IP Addresses/ Remote Network Mask through the
VPN connection. This is usually used when you find there are
several subnets behind the remote VPN router.
The option specifies the direction of RIP (Routing Information
Protocol) packets. You can enable/disable one of direction
here. Herein, we provide four options: TX/RX Both, TX Only,
RX Only, and Disable.
If the remote network only allows you to dial in with single
145
