LED
ACT (Activity)
IDP (Intrusion Detection and
Prevention)
Virus
WLAN
WAN1/2
MGMT
VPN
QoS
LED on Connector
WAN 1/2
LAN 1/2/3/4
4
o r P r o 5 3 0 0 n
o r P r o 5 3 0 0 n
Left LED
(Green)
Right LED
(Green)
Left LED
(Green)
Right LED
(Green)
Status Explanation
Blinking The router is powered on and running normally.
Off The router is powered off.
On The anti-intrusion function is enabled.
(Yellow)
On The anti-virus function is enabled.
(Yellow)
On
Wireless access point is ready.
Blinking
It will blink slowly while wireless traffic goes
through.
If ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and it will
return to normal condition after two minutes. (You
need to setup WPS within 2 minutes.)
On The WAN1 or WAN2 connection is ready.
Blinking It will blink while transmitting data.
On The router is managed (handled) by Telnet.
Blinking
It will blink while being managed by IE browser.
On The VPN tunnel is active.
On The QoS function is active.
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is connected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is connected with 10Mbps.
VigorPro5300 Series User's Guide
