8.1. Installation of the Equimatic model.

Secure the hopper to the wall with the kit of screws that is supplied with the unit. Installation
height shall be appropriate to the animals it will feed.

8.2. Installation of the Equimatic Duplo model.

In the Equimatic Duplo, the feeder and the hopper are independently supplied. Thus, the
hopper can be installed in areas that cannot be accessed by the animals.
A metal tray is provided to communicate the hopper and the feeder.
The installation procedure is as follows:
•
Secure the hopper to the wall with the fixing kit supplied with each unit.
Fig. 8 View of the assembly of the standard model.
INSTRUCTION MANUAL
INSTALLATION
ASSEMBLY AND
ADJUSTMENT
Page 18 of 29
