COPELE EQUIMATIC Instruction Manual page 43

2
1
4
1. Switch that puts the machine into operation.
2. Input plug of the 12 VDC charger/feeder pin.
3. Thermomagnetic for the protection of the 1 A motor.
4. Electric motor.
5. Compartment of the 12 V/7 Ah battery.
IF THE BATTERY OF THE EQUIMATIC HOPPER IS NOT USED
FOR THREE MONTHS, IT MUST BE RECHARGED. OTHERWISE, IT
Fig. 5 View of the electrical installation.
Fig. 6 View of the rechargeable battery.
WOULD GET DISABLED.
INSTRUCTION MANUAL
ELECTRICAL
INSTALLATION
5
3
Page 13 of 29
