Yealink MVC Series Quick Start Manual
For microsoft teams rooms system
Hide thumbs
Also See for MVC Series:
- Deployment manual (70 pages) ,
- Quick start manual (24 pages) ,
- Deployment manual (42 pages)
Subscribe to Our Youtube Channel
Related Manuals for Yealink MVC Series
Summary of Contents for Yealink MVC Series
- Page 1 V32.35 Yealink Network Technology CO., LTD Yealink MVC Series for Microsoft Teams Rooms System Quick Start Guide(V1.6) English | 简体中文...
- Page 2 Package Contents MVC900 Package 3m RCA to Camera-Hub Camera-Hub USB3.0 to Ethernet 7.5m Cable Tie×5 Power Adapter 3.5mm Audio Cable Quick Start Guide Ethernet Cable Adapter Camera-Hub Package (1/4”-20 UNC screw) Power Adapter VESA Accessory VCR20 UVC80 2.5m 7.5m 48V/0.7A Remote Control USB Cable Ethernet Cable...
- Page 3 MVC900 & MVC800 & MVC500 & MVC300 Connection MVC900 Connection UVC80 UVC80 CAT5e CAT5e CAT5e Switch Camera-Hub CAT5e 3m RCA to HDMI Display 3.5mm Audio Cable USB3.0 to Ethernet Adapter Projector HDMI MSpeaker(Optional) The Back of Mini-PC The Front of Mini-PC CAT5e HDMI HDMI...
- Page 4 UVC30 Room camera), refer to the Quick Start Guide of corresponding accessory. Wireless Sharing You can use Yealink WPP20 wireless presentation pod for wireless content sharing. WPP20 needs to be purchased separately. Make sure the MShare is connected to the mini-PC.
- Page 5 Upgrading System Software through Windows Update The system software(including the Windows, the Camera-Hub/UVC80/UVC50/UVC30 Room, the MTouch and the MShare) can be automatically upgraded via windows update by default. Otherwise, you can enable automatically windows update or upgrade the devices manually. Enabling Automatically Windows Update Procedure 1.
- Page 6 Enabling/Disabling Auto-framing Procedure 1. Tap to enter the Camera Control page. More-> 2. Select 3. Enable/Disable Auto-framing. Controlling UVC80/UVC50/UVC30 Room Camera Position Procedure 1. Tap to enter the Camera Control page. More-> 2. Tap to zoom camera in/out. 3. Tap to pan/tilt the camera.
