Welcome
Before you start
VI. Rename Existing HDD Partition Name
VII. Delete HDD Partitions
VIII. Change HDD Partition Size
Load Default Settings
Reflex Duplicator Manual
Page 2
Page 2
Page 4
Page 12
Page 24
Page 27
Page 30
Page 34
Page 37
Page 39
Page 41
Page 43
Page 53
Page 58
Page 62
Page 67
Page 67
Page 67
Page 67
Page 68
Page 68
Page 70
Page 72
Page 73
Page 75
- 1 -
t
Welcome!
Thank you for buying this Disc Makers duplicator. The Reflex DVD
and CD duplicator will make it easier than ever to duplicate vast
quantities of discs. This manual contains detailed information
about using all the features in your stand-alone Reflex duplicator.
******************************************************
Before you start:
Before you start using this duplicator, please read the following to
ensure proper operation:
1. DVD Duplication Limitations:
This duplicator, it will not copy any DVD that has Copy
Protection encoded inside. DVDs you purchase or rent from a
store will be Copy Protected.
In addition to the copy protection limitation, the duplicator
will only copy a DVD-5 format (4.7GB) disc to DVD-5 format
(4.7GB) recordable DVD media. If your duplicator has double
layer capability, you can copy a DVD-9 format (8.5GB) disc to
DVD-9 format (8.5GB) recordable DVD media. You cannot
duplicate a DVD5 format disc to a DVD9 format recordable
media or vice versa.
2. Temperature Warning:
hours, please leave the duplicator in a warm room with
temperatures at least 65ðF (19ðC) for 4 hours prior to
powering it on for the first time. Failure to do so may cause
irreparable harm and prevent the duplicator from functioning.
Reflex Duplicator Manual
- 2 -
Advertisement
Table of Contents
Related Manuals for Disc Makers Reflex10
Summary of Contents for Disc Makers Reflex10
-
Page 1: Table Of Contents
Load Default Settings - 1 - Welcome! Page 2 Thank you for buying this Disc Makers duplicator. The Reflex DVD Page 2 and CD duplicator will make it easier than ever to duplicate vast quantities of discs. This manual contains detailed information about using all the features in your stand-alone Reflex duplicator. -
Page 2: Tutorial Guide
This process will copy your master disc to several blank discs simultaneously. When you turn on your duplicator, after it has booted up, you should see the following signifying your duplicator is ready. Disc Makers 1. COPY 1. Make sure the Master Reading Source is set to the READER. - Page 3 Press “ENT“ to submit your selection. 2. Go back to “COPY“ Menu. a. Use UP or DOWN arrow button to navigate to the following screen: Disc Makers 1. COPY 3. Start the Copy Process. a. Insert your master disc and your blank discs into the corresponding tray(s) and press “ENT“...
- Page 4 Reflex Duplicator Manual To specify the number of copies for your project, you need to enter/input a 4-digit number. If you are planning to specify a number that is less than 4 digits, please fill the leading spaces with “0“s (any leading “0“ will be skipped). An example of that 4- digit number could be “0234“...
- Page 5 Reflex Duplicator Manual By default, the “Auto Start“ setting is set to “Auto“. For example, if your duplicator has detected 3 blank discs and didnít detect any additional blank discs within 30 seconds, then the duplication will start automatically. Once the number of blank discs you inserted matches the number of discs detected on the screen.
-
Page 6: Ii. Make Hard Drive(Hdd)-To-Disc Copies
Reflex Duplicator Manual If you enabled the counter and the number of discs you have inserted is more than what you requested, you will receive a message regarding you have inserted more discs than what you need. You can continue to copy or you can eject the extras. - Page 7 How to make copies from the Hard Drive? When you turn on your duplicator, after it has booted up, you should see the following signifying your duplicator is ready. Disc Makers 1. COPY Make sure the Master Reading Source is set to the Hard Drive.
- Page 8 Reflex Duplicator Manual partition and press “ENT“ to submit. You will see the following: Edit Partition Name ] OK? d. Name the partition you are about to load into the Hard Drive. To enter the name, you need to use the UP or DOWN buttons to select the character and use “ENT“...
- Page 9 Image 3.2 Load Partition b. Use UP or DOWN arrow button to navigate to the following screen. Disc Makers 1. COPY Start the Copy Process. a. Now, please insert your blank discs into the writer trays (make sure the Reader Tray is empty) and press “ENT“...
- Page 10 Reflex Duplicator Manual To enter the number, you need to use UP or DOWN button to select the number for each digit and use “ENT“ or “ESC“ button to move the cursor position right or left, once youíve finished, move the cursor to “OK“ and press “ENT“. For example, if I want to specify a counter value of 21 (twenty one).
- Page 11 Reflex Duplicator Manual Once the number of blank discs you inserted matches the number of discs detected on the screen. Then press “ENT“ (if you are not using Auto Start or wish to speed up the process) to confirm and the following Processing screen will appear.
-
Page 12: Select The Duplication Speed
When you turn on your duplicator, after it has booted up, you should see the following signifying your duplicator is ready. Disc Makers 1. COPY Navigate to Speed Selection Menu. Press UP or DOWN arrow button to navigate to the following screen. - Page 13 Reflex Duplicator Manual Disc Makers 5. Setup Press “ENT“ and the first option will be: Setup 5.1 Select Burn Speed Enter Speed Selection Menu. Then, you can press “ENT“ button to enter into Speed Selection Menu. You shall see the following:...
-
Page 14: Select The Master Reading Source
When you turn on your duplicator, after it has booted up, you should see the following signifying your duplicator is ready. - 27 - Reflex Duplicator Manual Disc Makers 1. COPY Navigate to Source Selection Menu. Press UP or DOWN arrow button or “Source“ hot key to navigate to the following screen. -
Page 15: Load Master Disc Onto The Hard Drive
Reflex Duplicator Manual Then you will be directed back to the menu: SetUp 5.2 Select Source After loading your master disc to the Hard Drive, please make sure to remove your master disc from the Master Reading Tray. Failure to do so might cause improper duplication. - Page 16 Reflex Duplicator Manual Hard Drive Port 0 WDC WD400EB-75CPF0 Make sure it is located at “Hard Drive“. If not, then you need to press UP or DOWN navigation button to search for it. c. Press “ENT“ to submit your selection. After your selection has been submitted, you will see the following: Setup...
- Page 17 To rename your existing hard drive partition name, please do the following: 1. Use UP or DOWN arrow button to navigate to the following screen. Disc Makers 3. Image 2. Press “ENT“ and use UP or DOWN arrow button to navigate to the following screen Image 3.
- Page 18 Reflex Duplicator Manual Choose Partition 1->[FUN ] DVD 4. Use UP or DOWN arrow button to find the desired partition and then press “ENT“ to submit your selection and you shall see the following confirmation screen: Rename Partition [FUN ] DVD, OK? 5.
- Page 19 Use UP or DOWN arrow button to navigate to the following screen. Disc Makers 3. Image Press “ENT“ and use UP or DOWN arrow buttons to navigate to the following screen: Image 4.
- Page 20 To change the hard drive partition size, please do following: 1. Use UP or DOWN arrow button to navigate to the following screen: Disc Makers 3. Image 2. Press “ENT“ and use the UP or DOWN arrow buttons to navigate to the following screen: Image 6.
-
Page 21: Change Setup Settings
1. Use UP or DOWN arrow button to navigate to the following screen. Disc Makers 5.Setup Press “ENT“ and use the UP or DOWN arrow buttons to navigate to the following screen: Setup 11. -
Page 22: Audio Cd Editing
CD-R disc. When you turn on your duplicator, after it has booted up, you will see the following screen: Disc Makers 1. COPY - 43 - Reflex Duplicator Manual Going to the “Edit Audio Track“... - Page 23 Reflex Duplicator Manual Once you made your selection, you shall see the following: Preparing... Waiting for Master Preparing... Waiting for a Blank When you see above, please insert an audio CD that contains your favorite track(s) in the Master Reading Tray and a blank CD-R media into one of Writer Trays.
- Page 24 Reflex Duplicator Manual If you choose to insert another audio CD for more songs, you need to press DOWN arrow button until you see the following screen: Total 6 Trk 26m:17s Insert Next Master?> Then, press “ENT“ button to continue. After that, your old master disc will be ejected and you can insert another audio CD into the Reading Tray.
- Page 25 Reflex Duplicator Manual Example of Editing Audio Tracks to Hard Drive (For Duplicators with Hard Drive Installed): We need to create a new Audio CD from 2 different Discs. CD1: song 2, and song 4 CD2: song 3, song 4 and song 5 1.
- Page 26 Then, you will be directed back to the main menu: Reflex Duplicator Manual Total: 2 Trk 9m:47s Finish Editing? > Total: 2 Trk 9m:47s Confirm to Finalize? Processing to Disc.. Job Completed! Press OK to Finish Disc Makers 4.AUDIO - 52 -...
-
Page 27: Account Management Feature
Account Management Feature Overview: To access the account management feature, you need to perform the following tasks: When you turn on the duplicator, you shall see following: Disc Makers 1. Copy Press UP or DOWN Button Consecutively until you see following: Disc Makers 6. - Page 28 Reflex Duplicator Manual digit of your password and press “ENT“ button to submit the current digit and you will be guided to select the next digit. Repeat above steps until youíve selected all digits of your password. After you have entered the password, you need to press “ENT“...
- Page 29 Reflex Duplicator Manual Manage Accounts 4. Delete User This menu allows you to delete the existing user account. During this process, you will be asked to select the existing account to be removed. - User “Admin“ is the administrative account; you can NOT delete this account.
- Page 30 “Copy“, “Test“, “Test + Copy“, and “Copy + Compare“. If you prefer not to be prompted each time you may set your preference by following the instructions below. When you turn on the duplicator, you shall see following: Disc Makers 1. Copy - 60 -...
-
Page 31: 10. Duplication Mode
Reflex Duplicator Manual Press UP or DOWN Button Consecutively until you see following: Disc Makers Setup Press “ENT“ and use the UP or DOWN arrows to navigate to the following: Setup 10. Duplication Mode Press “ENT“ button once. You shall see following:... - Page 32 Setup 11.AUTOCOPY 5. Press “ESC“ once to go back to following screen: Disc Makers 5. Setup If you wish to deactivate this feature, please follow the same steps above to turn this feature off.
- Page 33 Reflex Duplicator Manual 10. Once the duplication run is completed, the successful copies will be ejected and you shall see the following screen: PASS 7 FAIL 0( Waiting for Blanks “PASS 7” indicates that you’ve just made 7 successful copies. “FAIL 0”...
-
Page 34: Menu Overview
Reflex Duplicator Manual Menu Overview: COPY This menu will guide you to make CD/DVD copies. Before you enter this menu to copy, please make sure you have selected the correct Master Reading Source. For more information, please refer to “Tutorial Guide I ñ Make Disc-to- Disc Copies“... -
Page 35: Utilities
Reflex Duplicator Manual two different modes, “Disc at Once“ and “Track at Once“. Unless you understand completely what they mean, we strongly suggest you to set it as “Disc at Once“. Max Audio VCD and CDG Speed - Audio CDís and Video CDís do not have internal error checking capability, so duplicating at too high a speed may cause frequent errors. -
Page 36: Shutdown
Reflex Duplicator Manual occurs, it tends to waste all of your blank recordable media. 5.3 System Info - By entering this menu, you will be able to see the many specification of your duplicator such as the firmware version, CPU type, RAM capacity. You can check the specifications by pressing UP or DOWN button 5.4 Device Info - By entering this menu, you will be able to... -
Page 37: If The Duplicator Was Stored In A Location Where The Temperature Dropped Below 32Ðf (0Ðc) Within The Past
Use “compare“ feature to check the copied disc. Based on our experience, the quality of your media plays a big role on this part. Try to use high quality media, such as Disc Makers Ultra media, to prevent such problems. - Page 38 Reflex Duplicator Manual 11. How do I reset my duplicator back to default? Use UP or DOWN arrow button to navigate to the following screen. Disc Makers 5. Setup II) Press “ENT“ to enter Setup Menu and you shall see the following: Setup 1.
