NetVanta 1224STR Web-GUI
NetVanta 1224R/1224STR
All-in-One Network Access: Modular WAN Interface, Firewall,
Ethernet Switch, IP Router, and Optional VPN
Product Specifications
Network Interfaces
NIM (Network Interface Modules)
E1/FE1
T1/FT1
■
■
E1/FE1 with G.703
T1/FT1 with DSX-1
■
■
ADSL
Dual T1
■
■
SHDSL
56/64K
■
■
Serial (V.35, X.21/V.11)
■
DIM (Dial Backup Interface Modules)
Analog Modem
ISDN BRI 'ST' and 'U'
■
■
24 Fast Ethernet Ports
10/100Base-T
Auto-duplex
■
■
Auto-rate
Auto-MDI/MDI-X
■
■
Gigabit Ethernet Port (1224STR PoE)
Two combo Gigabit Ethernet port
■
supporting both 10/100/1000Base-T
and SFP for copper or optical connectivity
Auto-duplex
■
Auto-rate
■
Auto-MDI/MDI-X
■
Console Port
DB-9
■
Switching Performance
Non-blocking
■
8,000 MAC Addresses
■
16-MB memory shared by all ports
■
Maximum Forwarding Bandwidth
1224R: 4.8 Gbps
■
1224STR: 6.8 Gbps
■
Routing Performance
133 MHz Motorola MPC 866
■
16 MB Flash
■
Status LEDs
Power
■
WAN: Link, Activity, Alarm, Test
■
DBU: Link, In DBU, Alarm, Test
■
Ethernet Port Status: Link, Activity, PoE Status
■
Protocols
eBGP/iBGP
■
OSPF
■
RIP (v1 and v2)
■
PIM Sparse Mode
■
Demand Routing
■
Policy-based Routing
■
GRE
■
ATM (ADSL)
■
Frame Relay
■
Multilink Frame Relay
■
Layer 3 Backup
■
DHCP
Client, Server, and Relay
■
Spanning Tree Support
802.1D Spanning Tree
■
802.1w Rapid Spanning Tree
■
Frame Relay
Point-to-Point
■
RFC 1490 Encapsulation (Multiprotocol Over Frame Relay)
■
LMI Types: LMI, CCITT (Annex A), ANSI (Annex D), Static
■
VLAN Support
Port based VLANs
■
802.1Q tagged trunked VLANs
■
Support for up to 255 active VLANs
■
Inter-VLAN routing
■
GARP VLAN Registration Protocol (GVRP)
■
Link Aggregation
802.3ad Link Aggregation
■
Support for six trunk groups
■
Trunk groups consist of up to eight access ports
■
Class of Service (Switching-Layer 2)
Enforces 802.1p priorities
■
DiffServ
■
Four output queues per egress port
■
Weighted Round Robin
■
Strict Priority Queuing
■
Quality of Service (Routing-Layer 3)
Low Latency Queuing
■
Weighted Fair Queuing (WFQ)
■
DiffServ aware/mark
■
Frame Relay Fragmentation (FRF.12)
■
Security
32 MB DRAM
■
Firewall
30,000 PPS
■
Stateful Inspection Firewall
■
Denial of Service (DoS) Protection
■
Access Control Lists (ACLs)
■
Application Level Gateways (ALGs)
■
Optional Virtual Private Network (VPN)
IPSec Tunnel Mode: 500 Tunnels
■
PPP
Encryption: DES, 3DES, and AES
■
■
Multilink PPP
Diffie Hellman Group Support:
■
■
PPPoE
■
❏
PPPoA
■
❏
IGMP v2
Hash Algorithms: MD5-HMAC and SHA1-HMAC
■
■
Authentication Mechanisms: XAUTH, X.509
RFC 1483
■
■
Digital Certificates, Preshared Keys, Secure ID,
HDLC
■
DSS Signature
PPP Dial Backup
■
PAP and CHAP
■
Multihoming
■
Group 1: MODP 768
Group 2: MODP1024
