Vector Fog VECTORFOG H400 Instruction Manual page 6

To start fogging
Once the machine has heated up for 10 seconds, first turn the "Close Valve" and then the chemical supply valve
slowly counter clockwise. On SF models you will need to switch the directional valve situated on top of the resonator
to fog oil based chemicals, by turning it clockwise.
STEP 1
Close Valve
To turn off the machine
Turn the "Chemical Supply Valve" clockwise to stop the supply of chemical to the resonator. Before turning the
"Close Valve" off, keep it running for 5-10 seconds to get rid-off any chemical mixture still in the system. Once you
are sure that all the Chemical has been burned off. Turn the Close Valve and press the STOP button located on top of
the fuel tank to stop the machine.
the order shown below. Failure to do this could cause the system to back-fire.
STEP 1
Close Valve
STEP 2
Chemical supply Valve
Important: Never switch off the machine without closing the chemical valves in
STEP 2
Chemical supply Valve
6
STEP 3
(SF MODEL ONLY)
Directional Valve
Turn right for Oil Based fogging
STEP 3
(SF MODEL ONLY)
Directional Valve
Turn right for Oil Based fogging
