Remove carbon deposits in the resonator with the wire brush provided. Use and forward and backward motion.
The machine doesn't fog or doesn't fog enough:
• Check that the chemical supply valve is opened. This is done by turning it anticlockwise. Make sure that the close
valve is set to the open position.
• Unscrew the main chemical inlet nozzle from the resonator and clean it using compressed air to remove any
blockages.
• Check there is no leaks in the chemical tank. Blow compressed air backwards though the chemical tube from the
inlet nozzle to see if any bubbles appear. Replace leaking parts if necessary.
01. Resonator & chemical Inlet nozzle
1. Ejection pipe
2. Inner cooling pipe
7. Ejection buffer
8. Ejection nipple
spring
13. Chemical pipe
14. Bolt
Parts Assembly
3. Outer cooling pipe
4. Bracket
9. Ejection nipple tube
10. Straight nipple
15. Protective cover
16. Bolt
10
5. Safety net
6. Ejection nipple plate
11. Ball valve
12. Straight nipple
17. Flat washer
18. Nut
