04. Carburettor
1. Venturi
2. Upper Gasket
7. Spring washer
8. Bolt
13. Ring
14. Nut
19. O-ring
20. Engine rear peg
25. Air gasket
26. Washer
31. Air gasket washer
32. Air gasket nut
3. Cone shaft
4. Petrol valve
board
9. Lower Gasket
10. Engine
15. Engine upper pipe
16. Plug
21. Reducer
22. Run tee
27. Air Gasket Bolt
28. Air elbow
33. Air gasket nut
www.vectorfog.com
11
5. Petrol valve
6. Petrol valve support
11. Ejection nozzle
12. Nozzle
17. Plug cap
18. Metal grip
23. Elbow
24. Explosion pipe
29. Extension hose
30. Air gasket bolt
