Infinity Syner-D Circadian Assembly Manual

Step 15:
15
Lift the footrest and slide one side
of the footrest mounting bracket
completely onto the chair body pin.
Fasten the clip over the pin to
secure. Carefully align the other
side of the mounting bracket with
the remaining pin and slide it on
too. Make sure to center the
footrest, then fasten the remaining
clip over the pin to secure both
sides of the footrest.
16
Step 16:
Flip the Main power switch
back ON. Your Circadian
Syner-D Massage Chair is
TM
now complete and ready to
use. Either wake up the
touch screen by tapping on
it and then hit POWER or
simply press the POWER
button on the quick access
panel.
Review chair for smooth operation. If things are not operating correctly,
Power on the
review all assembly steps. Call Infinity support at 1-603-910-5000 if you
remote and
need live US-based support.
select AUTO
If you wish to use an APP to control the chair, download from the Apple
program to
or Google app store and follow pairing instruction found within the APP.
start a session.
You are done; time for a Massage!
Register your product at www.infinitymassagechairs.com/
warranty to ensure it is in our system. This will simplify the
warranty process should you ever need it.
Alternatively, scan the QR code to go directly to the URL above.
SCAN CODE
72 Stard Road, Seabrook, NH 03874 (603) 910-5000 www.infinitymassagechairs.com
Chair Footrest
Body Pin Mounting Bracket
Clip
Version 1.2
Assembly
Guide
Circadian
Massage Chair
S -D
yner TM
