Summary of Contents for Triplett LT65
- Page 1 User Manual LT65 Digital Light Meter GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 2 Introduction Congratulations on your purchase of the Triplett LT65 Digital Light Meter. The LT65 Digital Light meter is designed for Light intensity measurement projects, quality control, health control and measuring Light intensity of various kind of environments, like factories, parking lots, schools, offices, transportation lines, schools and many other environments.
-
Page 3: Display Overview
Display Overview ：Maximum display symbol. ：Minimum display symbol. GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 4: Function Buttons
： Low battery symbol, which shows the power is low battery. Please change a new battery. ：Data hold symbol TIME ：Time display, format: hour : minute Function Buttons TIME HOLD ：Long press the button "TIME" for 2 seconds to enter the time setting page. -
Page 5: Operation
：Range selection function. Range selection function will disable under the “REC” function. Choose measurement range before enter “REC” function. ：Backlight Function ：Changes UNITS Fc/Lux 1FC=10.76Lux,1KLux=1000Lux,1KFC=1000FC ：Power ON / OFF Button To Power ON – Press and Hold this button for more than 1 second until LCD screen full of display. -
Page 6: Battery Replacement
Lux or FC unit. Transfer light probe cover and make it vertical to aligned light source. Read the measurement data from LCD screen. Over range: If the instrument only display“OL”, means the signal input is too strong, should choose a higher range. Measurement range will display below the LCD screen. - Page 7 Triplett / Jewell Instruments extends the following warranty to the original purchaser of these goods for use. Triplett warrants to the original purchaser for use that the products sold by it will be free from defects in workmanship and material for a period of (1) one year from the date of purchase.
- Page 8 Specifications Display 4 Digit LCD Display Measurement Range 0 to 400,000 Lux; 0 to 40,000 Fc 1 Fc = 10.76 Lux; 1kLux = 1000 Lux; 1k Fc Notices = 1000 Fc Overload Display LCD displays "OL" Spectral CIE Appropriate Light (CIE eye response Response curve) Spectral...
