GB
Caution! Special care is required when making
double mitre cuts.
Do not overload your tool!
Wear safety goggles.
Wear a breathing mask on dusty jobs.
Examine the power cable / extension cable for
damage.
To prevent the saw from toppling backwards,
fasten both supporting feet (a) to the left and right
on the rear side of the saw with 2 screws each,
as illustrated in Fig. 11.
Wear goggles
Wear ear-muffs
Wear a breathing mask
Noise emission values
The saw's noise is measured in accordance with
DIN EN ISO 3744; 11/95, E DIN EN 31201; 6/93,
ISO 7960 Annex A; 2/95. The machine may
exceed 85 dB(A) at the workplace. In this case,
noise protection measures need to be introduced
for the user (ear-muffs).
Cutting
Sound pressure level LPA 92,4 dB(A) 93,3 dB(A)
Sound power level LWA 105,4 dB(A) 106,3 dB(A)
„The quoted values are emission values and not
necessarily reliable workplace values. Although there
is a correlation between emission and immission
levels it is impossible to draw any certain conclusions
as to the need for additional precautions. Factors
with a potential influence on the actual immission
level at the workplace include the duration of impact,
the type of room, and other sources of noise etc.,
e.g. the number of machines and other neighbouring
operations. Reliable workplace values may also vary
from country to country. With this information the
18
14:20 Uhr Seite 18
user should at least be able to make a better
assessment of the dangers and risks involved."
5. Technical data
Asynchronous motor
Power rating
Operating mode
Idle speed n0
Carbide saw blade ø 210 x ø 30 x 2.5 mm
Number of teeth
Connector for dust extractor
Standing area
As bench-type circular saw:
Saw table
Cutting height
Parallel stop swinging range
As mitre box saw:
Tilting range
Mitre cuts 0° to 45° to the left
Saw bed support
Sawing width at 90°
Sawing width at 45°
Sawing width at 2 x 45°
(double mitre cuts)
6. Before putting the machine into
operation (Abb. 1-3)
6.1 General information
The machine has to be set up where it can stand
firmly, e.g. bolt it to a work bench, a universal
base or similar.
Idling
All the covers and safety devices have to be
properly fitted before the machine is switched on.
It must be possible for the saw blade to run
freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machine's moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
To prevent the saw from toppling backwards,
fasten both supporting feet (a) to the left and right
230 V 50 Hz
1200 W
S1
4600 rpm
24
ø 35 mm
400 x 285
360 x 250 mm
0 - 33 mm
-30° to +30°
-45° / 0° / +45°
390 x 140 mm
120 x 55 mm
65 x 55 mm
40 x 23 mm
