C11G (Rev.8.2) User Manual
3. Specifications.
On-state voltage range
Maximum off-state voltaje
Maximum operation frequency
Typical signal delay
Maximum output voltage
Typical output current
Maximum off-state voltaje
Maximum operation frequency
Typical signal delay
Time of transition to high impedance state
*Time passed since a low in the ENABLE input is detected and the outputs are disabled
Requirements:
It requires a 5VDC @ 1000 milliamps power supply to operate.
WARNING
Check the polarity and voltage of the external power source and connect the 5V
and GND. Overvoltage or reverse-polarity power applied to these terminals can
cause damage to the board, and/or the power source.

4. Functional Block Diagrams

4.1 Outputs 2-9 simplified functional block diagram
Revision: 01/27/2010
DIGITAL INPUT SPECIFICATIONS
DIGITAL OUTPUT SPECIFICATIONS
http://cnc4pc.com/TechDocs/C11GR8_2_User_Manual.pdf 3/21
2 to 5V DC
0.8V
4 MHz
10nS
(5V power supply voltage) + 0.5V
24mA
0.44 V
4 MHz
10 nS
12 nS*
