Technical Reference
020-001940-01
E510 LED Display Controller
Serial Commands

Advertisement

loading
Need help?

Need help?

Do you have a question about the E510 and is the answer not in the manual?

Questions and answers

Related Manuals for Christie E510

Summary of Contents for Christie E510

  • Page 1 Technical Reference 020-001940-01 E510 LED Display Controller Serial Commands...
  • Page 2 Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection with the performance or use of this material.
  • Page 3 Display mode setting ......................26 Calibration control ....................... 27 Reconnect sending card or receiving card ................27 Parameter store ........................28 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 4 Echo typed characters locally: Checked Learn the format for request and acknowledge data packages. The following provides information about the request data package. E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 5 1, and so on. Device type Devices with control port properties, — such as sending cards, TV cards. Receiving card E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 6 • Checksum = 32 + FE + 01 + 0A + 01 + 5555 = 5961, so checkout[7:0]=61, checkout[15:8]=59 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 7 Command failed due to check error on acknowledge data package. Command failed due to invalid command. Reserved 06H-FFH Reserved E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 8 • Code is 01H—Section does not exist. Checkout [7:0] Low 8 bits of the checksum. E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 9 Number 13 does not exist because the Code is 01 and the write data does not exist. • Checksum = 5D + FE + 01 +10 + 05 + 5555 = 56C6, so checkout[7:0]=C6, checkout[15:8]=56 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 10 Use the E510 LED Display Controller commands to modify product settings. Change the display to black to simulate a power off command. Set the display to black. Request command: 55 AA 00 80 FE 00 01 00 FF FF 01 00 00 01 00 02 01 00 FF D6 59 0D 0A Set the back to normal.
  • Page 11 The speed of Fan 1 as Highest bit is for data validation. monitored by the monitor • 0—Invalid data card. • 1—Valid data E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 12 2 as monitored by the • 0—Invalid data monitor card. • 1—Valid data • 2 to 7—Voltage value Range: 0 to 127 V E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 13 Reports whether the cabinet Bit0—First cabinet doors are open. Bit1—Second cabinet • 0—Closed • 1—Open 0x000042 Reserved Reserved — 0x0000ff E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 14 Identify whether the signal is being received. • Device: Sending card • Base address: 02000000 H • Data length: 8H E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 15 • 0x1C:DVI Turn the power supply switch on and off. • Device: Function card • Base address: 05000000 H E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 16 No.13—Status of the power supply switch • 00—On • 01—Off Adjust the overall brightness, as well as the brightness of each color component. E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 17 55 AA 00 15 FE 00 01 00 FF FF 01 00 01 00 00 02 05 00 80 80 80 80 80 F0 5A 0D 0A Acknowledge data package: E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 18 • y—Output value of gamma transform • m—Data width of output value • x—Input value of gray scale E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 19 Base address: 0x0500_0000H • Data length: 400H Bits Attribute Command Name 0x000000 GammaTable Read/Write … 0x0003ff Parameter store (on page 28) E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 20 AA 55 00 15 00 FE 00 00 00 00 00 00 04 00 10 04 04 00 04 03 00 00 8B 56 04 03 00 00—FPGA program version is 4.3.0.0 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 21 • Base address: 0x0000_0000H • Data length: 2H Model ID (low-byte) Device type Model ID (high-byte) E510 0x11 0x5F E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 22 AA 55 00 32 00 FE 02 00 00 00 00 00 02 00 00 00 02 00 01 81 0D 57 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 23 Base address: 0x0800_0000H • Data length: 1H Bits Desription Offset (H) Name 0x00 Read/Write EDID Register0 … … … … E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...

  • Page 24: Register Value

    The value of each function refers to the Receiving card display function table. 0x00 (Default) Register value Description 0x00 Reserved 0x01 Reserved 0x02 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...

  • Page 25: Hardware Identification

    AA 55 00 80 00 FE 01 00 FF FF 01 00 01 01 00 02 00 00 D7 58 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 26 AA 55 00 80 00 FE 01 00 FF FF 01 00 02 01 00 02 00 00 D8 58 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 27 Any result other than 00 controller model ID indicates the card is connected. Read High byte of the controller model ID E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 28 AA 55 00 15 00 FE 01 FF FF FF 01 00 11 00 00 01 00 00 79 59 E510 LED Display Controller Technical Reference 020-001940-01 Rev. 1 (07-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
