C-Bow Taschenhalter / C-Bow holder
Yamaha MT-03
2020-
Artikel Nr.: / Item-no.:
4567
630
00 01
INHALT
CONTENT
2x 700007063 C-Bow schwarz
1x 700009082 Halter vorne links
1x 700009083 Halter vorne rechts
1x 700009084 Halter hinten
1x 700010898 Schraubensatz:
1x C-Bow Verlegung vertikal 720630 00 01
2x Zylinderschraube M5x35
4x Linsenschraube M8x45
2x U-Scheibe Ø5,4
4x U-Scheibe Ø8,4
8x U-Scheiben Ø6,4
Beladung der C-Bows nur 3kg / Seite
Max load of C-Bows only 3 kg / each side
Baubreite 42 cm
Width: 42 cm
schwarz/black
Kombinierbar mit Sportrack
Can be combined with
Sportrack
2x 700007063 C-Bow black
1x 700009082 Holder front left
1x 700009083 Holder front right
1x 700009084 Holder rear
1x 700010898 Screw kit:
1x C-Bow shifting vertical 720630 00 01
2x Allen screw M5x35
4x Filister head screw M8x45
2x Washer Ø5,4
4x Washer Ø8,4
8x Washer Ø6,4
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for hepco & becker 6304567 00 01
Summary of Contents for hepco & becker 6304567 00 01
- Page 1 C-Bow Taschenhalter / C-Bow holder Yamaha MT-03 2020- Artikel Nr.: / Item-no.: 4567 00 01 schwarz/black INHALT CONTENT 2x 700007063 C-Bow schwarz 2x 700007063 C-Bow black 1x 700009082 Halter vorne links 1x 700009082 Holder front left 1x 700009083 Halter vorne rechts 1x 700009083 Holder front right 1x 700009084 Halter hinten 1x 700009084 Holder rear...
- Page 2 4 plastic pins. Spoiler is obsolete. Pic.2: Dismantle the now accessible two original screws of the license plate bracket. Screws are obsolete. Bild 1/ Pic.1: Bild 2: / Pic.2: Bild 1 Pic 1P Bild 2 ic 2 6304567 00 01...
- Page 3 Fastening of the holder front left/right: Dismantle the two original screws of the footrest holders. Screws are obsolete. The holders will be fixed between frame and footrest holder. Use filister head screws M8x45 with washers Ø8,4. 6304567 00 01...
- Page 4 Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage. Hepco & Becker GmbH Tel.: +49 (0)6331 - 1453 - 100 An der Steinmauer 6 Fax: +49 (0)6331 - 1453 - 120 D-66955 Pirmasens eMail: vertrieb@hepco-becker.de Germany www.hepco-becker.de 6304567 00 01...
