Autoclima FRESCO 5000 BACK Assembly page 20

Remove the condenser cover.
Rest the template provided behind the cab, in the point considered most suitable for the assembly of the condenser.
PAY SPECIAL ATTENTION TO THE CONDENSER'S POSITION IN ORDER TO AVOID INTERFERENCE BETWEEN IT AND THE
MACHINE-MEMBERS FIXED ON THE CHASSIS, DURING SWINGING OR DURING CABIN'S OVERTURNING.
Choose 4 among the 11 slots from the condenser's template, 2 ON EACH SIDE, SO THAT THEY ARE AS FAR AS POSSIBLE FROM
EACH OTHER, TRIYING TO MATCH THEM WITH THE RIBS PRESENT IN THE BODY OF THE VEHICLE.
Should there be differences of levels on the cabin's back wall, in the condenser's area, use adequate spacers.
Mark the 4 fastening spots on the chassis and make the Ø13 holes. Spread antioxidant around the holes, then insert the 4 M8 caged inserts
given, pulling them properly. SPREAD THE SEALANT VERY CAREFULLY AROUND THE FASTENING POINTS (SEE FIG.7 PAG.15)
Rest and block the condenser using the screws supplied with relative washers.
SEAL the Ø60 hole with grommet made on the vehicle's chassis and the hole made for the draining of condensed water VERY ACCU-
RATELY with polyurethane foam and silicone.
Protect with the small corrugated jacket the capillary hose where required.
Assemble the 90° TERMINAL: make 3 holes on the outer border on the most appropriate points for its fastening, drilling the bodywork
at the back. Spread the sealant well on all the area of contact between the terminal and the vehicle's wall; put the antioxidant and
the sealant around the holes made on the chassis, then fasten it with the self-tapping screws 3.9x16 given after the terminal has been
positioned.
Fasten the coolant pipe to the bodywork using the pipe clamp with the screws supplied, drilling the necessary holes, after applying
an appropriate rustproof seal (SEE FIG.9 PAG.15)
Assemble the cover of the evaporator block inside the cab (SEE PAG.16)
Install to the outside the covering of the condenser block (SEE PAGE 16)
Before to make the refrigerating charge, (through the charge id fitting placed on the condenser block) make 30 min. vacuum cycle.
Put into the circuit ca. 500 grams of R134a.
Switch the FRESCO 5000 BACK on for ca. 10 minutes before to disconnect the charging hose.
When the refrigerating charge cycle is over, the leakages and the correct operation of the system should be checked.
IT EN FR DE ES
CONDENSER ASSEMBLY
FINISHING OPERATIONS
COOLANT FILLING PROCEDURE
