Lifetime 90762 Assembly Instructions Manual

ADVENTURE TOWER
PLAYSET
MODEL #60091
MODEL 90762
BEFORE ASSEMBLY:
• Prepare a level surface with the proper Safety Zone
(see page 12).
• 3 people recommended for setup
Save this instruction in the event that the manufacturer has
to be contacted for replacement parts.
For Customer Service in Mainland Europe and the United Kingdom»
E-mail : cs@lifetimeproducts.eu
TOOLS REQUIRED
1/2 in/po (≈13 mm)
(1)
(2)
3/8 in/po (≈10 mm) 5/16 in/po (≈8 mm)
(1)
QUESTIONS?
CONTACT LIFETIME CUSTOMER SERVICE:
Call: 1-800-225-3865
7:00 am–5:00 pm (Monday–Friday) MST
and 9:00 am–1:00 pm Saturday MST
(1)
(1)
(3)
(1) (1)
Live Chat: www.lifetime.com
(click on "Ask An Expert" tab)
Video Instructions:
www.youtube.com/lifetimeproducts
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
1/2 in/po (≈13 mm)
9/32 in/po (≈7mm )
(2)
3/16 in/po (≈5 mm)
(2, included)
(1)
(1)
(1) (1)
TABLE OF CONTENTS
Icon Legend................................4
Warnings & Notices.....................5
Safety Information.....................6
(1)
Safe Play Area...........................12
Tower Frame Assembly..............13
Swing Bar Assembly..................27
Deck Assembly..........................34
Parts Identifi er..........................i-iv
Roof Assembly..........................50
Tower Walls Assembly................57
Climber, Slide & Swing
Assembly............................68
Anchor Kit Installation...............77
Maintenance Instructions..........82
Registration...........................85
Warning Sticker........................86
Warranty..............................87
MODEL# AND PRODUCT ID
(you will need both when contacting us)
Model Number: 90762
Product ID:
