Lifetime 90797 Assembly Instructions Manual

DOUBLE SLIDE
PLAYSET WITH
MINI-GO-ROUND
MODEL #60091
MODEL 90797
BEFORE ASSEMBLY:
• Prepare a level surface with the proper Safety Zone
(see page 12).
• 2+ people recommended for setup.
• Inspect all parts and hardware. Ensure all are
included using the Parts Identifier in the middle
of these instructions. The Parts Identifier , in
yellow, can be removed from the instructions for
quick reference.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
TOOLS REQUIRED
(1)
(1)
QUESTIONS?
CONTACT LIFETIME CUSTOMER SERVICE:
Call: 1-800-225-3865
7:00 am–5:00 pm (Monday–Friday) MST
and 9:00 am–1:00 pm Saturday MST
(English, French, Spanish)
®
ADDITIONAL ASSEMBLY HELP
ASSEMBLE IT WITH THE FREE BILT INTELLIGENT
INSTRUCTIONS APP
IN THE APP, SCAN OR SEARCH #1208441
7/16 in/po (≈11 mm)
(1, included)
(2)
1/2 in/po (≈13 mm)
#3
(1)
(1)
3/16 in/po (≈5 mm)
(2, included)
(1)
1/4 in/po (≈6 mm)
(1)
Live Chat: www.lifetime.com/customerservice
(click on "LIVE CHAT" tab)
For customer service in mainland Europe:
E-mail: cs@lifetimeproducts.eu
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
(1)
3/8 in/po (≈10 mm)
(1)
(1)
(2)
TABLE OF CONTENTS
Icon legend................................4
Warnings and notices..................5
Safety information.....................6
Safe play area..........................12
Spare hardware bag.................13
A-frame assembly......................14
Deck support assembly..............20
Mini-Go-Round assembly...........33
(1)
Deck assembly..........................43
Parts identifi er..........................i-iv
Climbing wall and chalkboard
assembly................................. 50
Roof assembly..........................57
Slide and accessories assembly ....
...............................................63
Swing assembly........................75
Maintenance instructions..........79
Registration..............................82
Warning sticker........................84
Warranty...................................85
MODEL# AND PRODUCT ID
(you will need both when contacting us)
Model Number: 90797
Product ID:
