Delta Electronics SIQ65 Specifications

SMT Power Inductor
SIQ65 Type
Features
RoHS compliant.
Small size (6.2mm*6.6mm), low profile (5.0mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.
Mechanical Dimension:
C
E
Electrical Characteristics:
PART NO.
(uH)
SIQ65 - 100
SIQ65 - 120
SIQ65 - 150
SIQ65 - 180
SIQ65 - 220
SIQ65 - 270
SIQ65 - 330
SIQ65 - 390
SIQ65 - 470
SIQ65 - 560
SIQ65 - 680
SIQ65 - 820
SIQ65 - 101 100
SIQ65 - 121 120
SIQ65 - 151 150
SIQ65 - 181 180
SIQ65 - 221 220
SIQ65 - 271 270
SIQ65 - 331 330
SIQ65 - 391 390
SIQ65 - 471 470
SIQ65 - 561 560
SIQ65 - 681 680
SIQ65 - 821 820
SIQ65 - 102 1000
1. Tolerance of inductance:
2. Irated is the DC current which cause the inductance drop less than 25% of its nominal inductance without current
and the surface temperature of the part increase less than 45
3. Operating temperature: -20 C to 105 C (including self-temperature rise)
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
B
D A
F
o
25 C, 1KHz, 1V
1
2
L
DCR Irated
( ) MAX
(Adc)
10 0.12 1.35
12 0.13 1.22
15 0.18 1.11
18 0.24 1.02
22 0.27 0.91
27 0.30 0.82
33 0.33 0.74
39 0.37 0.69
47 0.52 0.62
56 0.56 0.58
68 0.63 0.51
82 0.71 0.46
1.03 0.42
1.15 0.38
1.68 0.35
1.87 0.32
2.08 0.29
2.37 0.26
2.67 0.23
2.94 0.22
3.93 0.20
5.43 0.18
7.32 0.17
8.24 0.15
9.26 0.14
20%.
o o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R .O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
2.0
1.5
4.1
1000.00
100.00
10.00
0.00
o
C.
20
UNIT:mm/inch
A = 6.6 ¡Ó 0.3 / 0.260 0.012 ¡Ó
B = 6.2 0.3 / 0.244 0.012 ¡Ó ¡Ó
C = 5.0 / 0.197 Max.
D = 4.6 0.2 / 0.181 0.008 ¡Ó ¡Ó
E = 5.9 0.3 / 0.232 0.012 ¡Ó ¡Ó
F = 1.5 0.2 / 0.059 0.008 ¡Ó ¡Ó
102
821
681
561
471
391
331
271
221
181
151
121
101
820
680
560
470
390
330
270
220
180
150.
120
100
0.01 0.10 1.00 10.00
CURRENT (A)
