Delta Electronics SMT Power Inductor SIQ73 Specification Sheet

SMT Power Inductor
SIQ73 Type
Features
RoHS compliant.
Magnetically shielded.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
Mechanical Dimension:
C

Electrical Characteristics:

L
PART NO.
(uH)
SIQ73A - R45 0.45
SIQ73A - 1R0 1.00
SIQ73 - 1R2 1.20
SIQ73C - 2R0 2.00
SIQ73A - 2R2 2.10
SIQ73C - 3R3 3.30
SIQ73 - 4R7 4.70
SIQ73C - 4R7 4.70
SIQ73C - 5R6 5.60
SIQ73C - 6R8 6.80
SIQ73 - 6R8 6.80
SIQ73 - 100 10.00
SIQ73 - 120 12.00
SIQ73 - 150 15.00
SIQ73 - 180 18.00
SIQ73 - 220 22.00
SIQ73 - 270 27.00
SIQ73 - 330 33.00
SIQ73 - 390 39.00
SIQ73 - 470 47.00
SIQ73 - 560 56.00
SIQ73 - 680 68.00
SIQ73 - 820 82.00
SIQ73 - 101 100.00
SIQ73 - 121 120.00
SIQ73 - 151 150.00
SIQ73 - 181 180.00
SIQ73 - 221 220.00
SIQ73 - 271 270.00
SIQ73 - 331 330.00
SIQ73 - 391 390.00
SIQ73 - 471 470.00
SIQ73 - 561 560.00
SIQ73 - 681 680.00
SIQ73 - 821 820.00
SIQ73 - 102 1000.00
1. Tolerance of inductance: 20% .
2. Isat is the DC current which cause the inductance drop less than 25% of its nominal inductance without current. ( 30% Typ. for SIQ73C)
3. Ir is the DC current which cause the surface temperature of the part increase less than 45
4. Operating temperature: -20 C to 105 C (including self-temperature rise).
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
B
D
E
A
F
o
25 C , 100KHz, 0.1V for 0.45~6.8uH. 1KHz,1.0V for 10~1000uH.
1
DCR 2
Isat
( ) MAX
(Adc)
0.0076 9.00
0.012 6.50
0.013 4.70
0.024 7.30
0.0152 20% 5.52
0.037 6.70
0.045 2.30
0.044 5.50
0.050 5.10
0.062 4.40
0.060 2.00
0.072 1.68
0.098 1.52
0.130 1.33
0.140 1.20
0.190 1.07
0.210 0.96
0.240 0.91
0.320 0.77
0.360 0.76
0.470 0.68
0.520 0.61
0.690 0.57
0.790 0.50
0.890 0.49
1.270 0.43
1.450 0.39
1.650 0.35
2.310 0.32
2.620 0.28
2.940 0.26
4.180 0.24
4.670 0.22
5.730 0.19
6.540 0.18
9.440 0.16
o o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
