Delta Electronics SIQ63 Specifications
Delta Electronics SIQ63 Specifications

Delta Electronics SIQ63 Specifications

Smt power inductor

Advertisement

Quick Links

SMT Power Inductor
SIQ63 Type
Features
RoHS compliant.
Small size (6.2mm*6.6mm), low profile (3.0mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.
Mechanical Dimension:
C
E
Electrical Characteristics:
L
PART NO.
(uH)
SIQ63 - 2R9
2.9
SIQ63 - 4R0
4.0
SIQ63 - 5R5
5.5
SIQ63 - 100
10.0
SIQ63 - 120
12.0
SIQ63 - 150
15.0
SIQ63 - 180
18.0
SIQ63 - 220
22.0
SIQ63 - 270
27.0
SIQ63 - 330
33.0
SIQ63 - 390
39.0
SIQ63 - 470
47.0
SIQ63 - 560
56.0
SIQ63 - 680
68.0
SIQ63 - 820
82.0
SIQ63 - 101
100.0
SIQ63 - 121
120.0
SIQ63 - 151
150.0
SIQ63 - 181
180.0
SIQ63 - 221
220.0
SIQ63 - 271
270.0
SIQ63 - 331
330.0
1. Tolerance of inductance:
2. Irated is the DC current which cause the inductance drop less than 25% of its nominal inductance without current
and the surface temperature of the part increase less than 45
3. Operating temperature: -20 C to 105 C (including self-temperature rise)
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
B
D
F
o
25 C, 2.9~5.5uH 100KHz, 0.1V. 10~330uH 1KHz,1V.
1
2
DCR
Irated
( ) MAX
(Adc)
0.068
1.94
0.080
1.63
0.096
1.40
0.150
1.10
0.200
1.00
0.230
0.90
0.270
0.80
0.340
0.74
0.380
0.66
0.450
0.59
0.490
0.54
0.690
0.50
0.780
0.46
1.070
0.42
1.210
0.38
1.390
0.34
1.900
0.31
2.180
0.28
2.770
0.26
3.120
0.23
4.380
0.22
4.940
0.19
20%.
o
o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
2.0
1.5
A
4.1
1000.00
100.00
10.00
1.00
0.00
o
C.
19
UNIT:mm/inch
A = 6.6
0.3 / 0.260 0.012
¡Ó
¡Ó
B = 6.2 0.3 / 0.244 0.012
¡Ó
¡Ó
C = 3.0 / 0.118 Max.
D = 4.6 0.2 / 0.181 0.008
¡Ó
¡Ó
¡Ó
E = 5.9 0.3 / 0.232 0.012
¡Ó
F = 1.5 0.2 / 0.059 0.008
¡Ó
¡Ó
331
271
221
181
151
121
101
820
680
560
470
390
330
270
220
180
150
120
100
5R5
4R0
2R9
0.01
0.10
1.00
10.00
CURRENT (A)
