Delta Electronics THAR1211C Specifications

Through Hole Power Inductors

THAR1285, 1290 & 1211C Type

Features

RoHS compliant.
High current ( lsat up to 40A ) though hole type.
Magnetically shielded, suitable for hight density mounting.
High energy storage and low DCR.
Ideal for power source circuits, DC-DC converter,
DC-AC inverters inductor application.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.

Mechanical Dimension:

A
E
A
E
PART NO. A (MAX)
THAR1285 11.9 / 0.469
THAR1290 11.9 / 0.469
THAR1211C 12.0 / 0.472

Electrical Characteristics :

PART NO.
THAR1285-R47
THAR1285-0R6
THAR1290-R19
THAR1290-0R3
THAR1290-1R2
THAR1290-1R8
THAR1211C-0R3
THAR1211C-0R5
1. Lo is the initial inductance and the tolerance is 20%.
2. Isat is the DC current which cause the inductance drop approximately 20% of its nominal inductance without current.
3. Irms is the DC current which cause the surface temperature of the part increase less than 45
4. Operating temperature : -40
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
D C
B
F
D C
B
F
1
B (MAX)
C
11.9 / 0.469 3.5 0.5 / 0.138 0.02
11.9 / 0.469 3.5 0.5 / 0.138 0.02
11.0 / 0.433 3.5 0.5 / 0.138 0.02
o
At 25 : 100KHz, 1V C
1
Lo
(uH)
0.47
0.60
0.19
0.30
1.20
1.80
0.30
0.50
O to 125 O ( including self-temperature rise ).
C C
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
2x G
5.70
6.30
2x G
5.70
6.30
D (MAX) E
8.5 / 0.335 8.5 0.3 / 0.335 0.012 1.5 0.1 / 0.059 0.004 1.8 / 0.071
9.0 / 0.354 8.5 0.3 / 0.335 0.012 1.5 0.1 / 0.059 0.004 1.8 / 0.071
11.0 / 0.433 8.5 0.3 / 0.335 0.012 1.4 0.1 / 0.055 0.004 1.7 / 0.067
DCR Isat
(m ) (Adc)
0.80 7% 50
0.80 7% 50
0.67 7% 60
0.80 7% 50
3.20 MAX 30
4.30 MAX 25
0.75 7% 40
1.00 7% 40
150
UNIT : mm/inch
G H
F
1
1
2
2 3
Irms
(Adc)
38
38
38
38
28
18
38
38
O
C.
