- Page 1 Getting Started With the Dell™ PowerVault™ ML6000 (ENG) Dell™ PowerVault™ ML6000 スタート ガイド (JPN) w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
- Page 2 Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
- Page 3 CAUTION: Before cabling your library, read the Dell™ PowerVault™ Systems Product Information Guide. CAUTION: All libraries must be installed in a rack having a main protective earthing (grounding) terminal. For detailed installation information, see the Dell™ PowerVault™ ML6000 Tape Library User’s Guide.
- Page 4 Install Your Library in a Rack All Dell™ PowerVault™ ML6000 libraries must be installed in a Dell PowerVault rack. For instructions, see the ™ Library User’s Guide • ML6010 CM is a single 5U Library Control Module. • ML6020 CM consists of one (1) ML6010 CM 5U Library Control Module and one (1) ML6000 EM 9U Expansion Module (14U total).
- Page 5 Connect SCSI Cables If your library uses only Fibre Channel drives, skip this step. There are two recommended ways to cable SCSI tape drives: two tape drives per SCSI bus or one tape drive per SCSI bus. To connect two tape drives per SCSI bus: Attach one end of the SCSI cable to the top SCSI port of the bottom tape drive.
- Page 6 Connect Fibre Channel Cables If your library uses only SCSI drives, skip this step. Use Fibre Channel cables to connect your host (or switch) to the library. For each tape drive: • Attach one end of the Fibre Channel cable to the Fibre Channel port on the tape drive.
- Page 7 Connect Module Cables and Module Terminators All libraries must use module terminators. Libraries that consist of multiple modules must use module cables. CAUTION: The module terminator is not the same as a SCSI terminator. Using a SCSI terminator instead of a module terminator can damage the library.
- Page 8 Connect the Ethernet Cable Ethernet ケーブルの接続 • Connect your Ethernet cable to the top Gigabit Ethernet port on • Ethernet ケーブルを、ライブラリ コントロール ブレード the library control blade (LCB). 『LCB 』の、上のギガビット Ethernet ポートに接続します。...
- Page 9 Connect Power Cords Power supplies are required for all modules that contain tape drives. For each power supply: • Attach one end of the power cord to the power supply. Then attach the other end to the power source. 電源コードの接続 テープ...
- Page 10 Power On the Library • Turn on each power supply’s power switch. Then turn on the library’s main power using the switch located on the front of the 5U Library Control Module. The Setup Wizard screen appears on the operator panel when the library has completed its POST and initialization.
- Page 11 Get Started • Configure your library using the Setup Wizard. For details, see the Dell PowerVault ML6000 Tape Library User’s Guide. ™ ™ • Verify that each host can communicate with the library’s tape drives. For details, see your host application documentation.
