Dell™ PowerVault™ 775N Systems Information Update Mise à jour des informations Aktuelle Informationen Actualización de la información w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is strictly forbidden. Trademarks used in this text: Dell, the DELL logo, and PowerVault are trademarks of Dell Computer Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation; Xeon is a trademark and Intel is a registered trademark of Intel Corporation.
Page 5
This document provides updated information about the following topics for your system: • Installing the SCSI cable strain-relief bracket • System features • Microprocessor features • System memory features • System board connectors for memory modules • Broadcom NetXtreme Gigabit Ethernet Server Adapter •...
F i g u r e 1 - 1 . strain-relief bracket captive thumbscrew System Features Your system contains the following new system features: • Up to two Intel internal operating speed of at least 2.0 GHz, and 512 KB of internal level-2 cache. NOTE: Your system does not support dual microprocessors with different front-side buses.
Page 7
Microprocessor Features The Intel Xeon microprocessors in your system provide NetBurst microarchitecture and Hyper-Threading Technology to significantly increase microprocessor performance. Hyper- Threading allows one physical microprocessor to appear as two logical processors to the operating system and application programs. Hyper-Threading also allows each microprocessor to simultaneously execute multiple tasks using shared hardware resources.
Page 8
System Board Connectors for Memory Modules See Figure 1-2 for the location and the updated description of the memory module connectors on the system board. For more information on system board connectors, see your Installation and Troubleshooting Guide. F i g u r e 1 - 2 . Infor m ation Update S y s t e m B o a r d C o n n e c t o r s f o r M e m o r y M o d u l e s BANK3_B connector...
Page 9
Broadcom NetXtreme Gigabit Ethernet Server Adapter When a Broadcom NetXtreme Gigabit Ethernet Server Adapter is installed and Wakeup On LAN (WOL) is enabled, your system’s connection speed is 10/100 Mbps. The Broadcom NetXtreme Gigabit Server Adapter only supports 10/100-Mbps links when WOL is enabled and the system is in Microsoft hibernation.
Page 21
Ce document contient des informations mises à jour sur les sujets suivants concernant votre système : • Installation du support de soulagement de tension des câbles SCSI • Caractéristiques du système • Caractéristiques du microprocesseur • Caractéristiques de la mémoire système •...
F i g u r e 3 - 1 . support de soulagement vis à molette captive Caractéristiques du système Votre système offre désormais les caractéristiques suivantes : • Jusqu'à deux microprocesseurs Intel frontal cadencé à 533 MHz, et d'un cache interne de niveau 2 à 512 Ko. REMARQUE : Votre système ne prend pas en charge de double microprocesseurs dotés de différents bus frontaux.
Page 23
Caractéristiques du microprocesseur Les microprocesseurs Intel Xeon de votre système sont équipés de la microarchitecture NetBurst et de la technologie Hyper-Threading qui permettent d'accroître considérablement les performances. La technologie Hyper-Threading permet à un microprocesseur physique d'être perçu comme deux processeurs logiques par le système d'exploitation et les programmes d'application.
Page 24
Les options de mémoire redondante varient selon le nombre de blocs de mémoire occupés et selon que des modules de mémoire identiques sont installés dans chaque bloc : • Disabled (Désactivé) — Un ou plusieurs blocks ne sont pas occupés, ou tous les modules de mémoire ne sont pas de taille et de type identiques.
Page 25
F i g u r e 3 - 2 . C o n n e c t e u r s d e l a c a r t e s y s t è m e p o u r l e s m o d u l e s d e m é...
Page 26
Lorsque le système d'exploitation se charge et que les pilotes adéquats sont installés, la vitesse de connexion prise en charge est de 10/100/1000 Mbps. Lorsqu'une prise en charge de la fonction WOL est requise, il est conseillé de connecter l'Adaptateur Broadcom NetXtreme Gigabit Server à...
Page 29
Dieses Dokument enthält aktuelle Informationen zu den folgenden Themen in Bezug auf Ihr System: • Installation der Zugentlastungsklammer für SCSI-Kabel • Systemmerkmale • Mikroprozessor-Merkmale • Systemspeicher-Merkmale • Systemplatinenstecker für Speichermodule • Broadcom NetXtreme Gigabit Ethernet Server Adapter • Spezielle Tastenfunktionen für Konsolenumleitung Installation der Zugentlastungsklammer für SCSI-Kabel Schalten Sie das System und alle angeschlossenen Peripheriegeräte aus, und ziehen...
Page 30
A b b i l d u n g 4 - 1 . Zugentlastungsklammer Selbstsichernde Flügelschraube Systemmerkmale Ihr System verfügt über folgende neue Systemmerkmale: • Bis zu zwei Intel MHz, einer internen Taktfrequenz von mindestens 2,0 GHz und einem internen Level 2-Cache von 512 KB.
Page 31
Mikroprozessor-Merkmale Die Intel Xeon-Mikroprozessoren des Systems enthalten eine NetBurst-Mikroarchitektur und die Hyper-Threading-Technologie, was die Leistung des Mikroprozessors deutlich steigert. Durch die Hyper-Threading-Technologie erscheint ein einzelner Mikroprozessor für das Betriebssystem und die Anwendungsprogramme wie zwei logische Prozessoren. Mit Hyper-Threading kann jeder Mikroprozessor außerdem mit geteilten Hardware-Ressourcen gleichzeitig verschiedene Aufgaben ausführen.
Page 32
• Disabled (Deaktiviert) — Ein oder mehrere Blöcke sind nicht belegt, oder die Speichermodule haben nicht alle den gleichen Typ und die gleiche Größe. • Disabled (Deaktiviert) und Spare Bank Enabled (Ersatzblock aktiviert) — Alle drei Speicherblöcke sind mit Speichermodulen desselben Typs und derselben Größe belegt.
Page 33
A b b i l d u n g 4 - 2 . S y s t e m p l a t i n e n s t e c k e r f ü r S p e i c h e r m o d u l e Broadcom NetXtreme Gigabit Ethernet Server Adapter Wenn ein Broadcom NetXtreme Gigabit Ethernet Server Adapter installiert und WOL...
Page 34
Wenn das Betriebssystem geladen wird und die Treiber installiert sind, beträgt die unterstützte Verbindungsgeschwindigkeit 10/100/1000 Mbit/s. Wenn WOL erforderlich ist, wird empfohlen, den Broadcom NetXtreme Gigabit Server Adapter an einen 10/100/1000- Verbindungspartner im Auto-Negotiation-Modus anzuschließen. WOL wird nur von einem Ethernet-Port im System unterstützt, dabei kann es sich nicht um den Systemverwaltungs-Port handeln.
Page 35
Dell™ PowerVault™ 775N システム w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
Page 41
Broadcom NetXtreme Gigabit Ethernet Server Adapter Broadcom NetXtreme Gigabit Ethernet Server Adapter Wake on LAN WOL Mbps Advanced Server Ethernet Server Adapter 10/100Mbps 10/100/1000 Mbps Broadcom NetXtreme Gigabit Server Adapter 10/100/1000 Broadcom NetXtreme Gigabit 5703 Ethernet adapter Hyper-Threading Console Redirection メモ:...
Page 43
Dell™ PowerVault™ 775N 시스템 w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
Page 45
• SCSI • • • • • Broadcom NetXtreme • SCSI 참고 : SCSI SCSI 랙 설치 안내서...
Page 46
그 림 6 - 1 . 고 정 완 화 브 래 킷 설 치 • 2.0 GHz 512 KB , 533 MHz ® Intel Xeon™ 참고 : • PC-2100 266MHz DDR SDRAM 참고 : BIOS...
Page 47
Intel Xeon NetBurst Threading • • • • System Setup Processor 활성화 입니다 ). . System Setup System Setup Redundant Memory • Disabled — • Disabled Spare Bank Enabled — Hyper-Threading Hyper-Threading CPU Information Hyper-Threading System Setup . Hyper- Logical 사용자...
Page 48
그 림 6 - 2 . 메 모 리 모 듈 용 시 스 템 보 드 커 넥 터 설치 및 문제 해결 설명서 BANK3_B BANK3_A BANK2_B BANK2_A BANK1_B BANK1_A...
Page 49
Broadcom NetXtreme Broadcom NetXtreme LAN) NetXtreme ® Windows 2000 Server . WOL 10/100/1000 NetXtreme 5703 Hyper-Threading " 참고 : 표 6-1 에 나온 ANSI 이스케이프 문자열 키 조합은 대소문자를 구분합니다 . 예 를 들어 <Insert> 문자를 만들려면 <Esc> 를 누른 후 <Shift><+> 를 눌러야 합니 다...
Page 51
Sistemas Dell™ PowerVault™ 775N Actualización de la información w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
Page 52
Queda estrictamente prohibida la reproducción de este documento de cualquier forma sin la autorización por escrito de Dell Computer Corporation. Marcas comerciales utilizadas en este texto: Dell, el logotipo de DELL y PowerVault son marcas comerciales de Dell Computer Corporation; Microsoft y Windows son marcas comerciales registradas de Microsoft Corporation; Xeon es una marca comercial e Intel es una marca comercial registrada de Intel Corporation.
Page 53
En este documento se proporciona información actualizada sobre los siguientes temas relacionados con el sistema: • Instalación del soporte de alivio de tensión del cable SCSI • Características del sistema • Características del microprocesador • Características de memoria del sistema •...
F i g u r a 7 - 1 . soporte de alivio de tensión tornillo mariposa cautivo Características del sistema El sistema contiene las siguientes características nuevas: • Hasta dos micropocesadores Intel MHz, una velocidad interna de al menos 2.0 GHz y una memoria caché L2 interna de 512 KB.
Page 55
Características del microprocesador Los microprocesadores Intel Xeon del sistema proporcionan una microarquitectura NetBurst y tecnología “Hyper-Threading” para incrementar significativamente el rendimiento del microprocesador. Hyper-Threading permite que un microprocesador físico aparezca como dos procesadores lógicos para el sistema operativo y para los programas de aplicaciones.
Page 56
• Disabled (Desactivado) y Spare Bank Enabled (Banco auxiliar activado): los tres bancos de memoria están ocupados con módulos de memoria del mismo tipo y tamaño. Conectores de la placa del sistema para los módulos de memoria Consulte la Figura 7-2 para ver la ubicación y la descripción actualizada de los conectores del módulo de memoria de la placa del sistema.
Page 57
F i g u r a 7 - 2 . C o n e c t o r e s d e l a p l a c a d e l s i s t e m a p a r a l o s m ó d u l o s d e m e m o r i a Adaptador de servidor Broadcom NetXtreme Gigabit Ethernet...
Page 58
Cuando se carga el sistema operativo y se instalan los controladores correctos, la velocidad de conexión admitida es de 10/100/1000 Mbps. Se recomienda que cuando se precise el soporte de WOL, el adaptador de servidor Broadcom NetXtreme Gigabit se conecte a un socio de enlace de 10/100/1000 en modo de negociación automática.
Page 60
Printed in the U.S.A. 美国印刷。 Imprimé aux U.S.A. Gedruckt in den USA. Impreso en los EE.UU. 0H2083A00 w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
Page 62
Printed in Ireland. 爱尔兰印刷。 Imprimé en Irlande. Gedruckt in Irland. Impreso en Irlanda. 0H2083A00 w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
Page 64
Printed in Malaysia. 马来西亚印刷。 Imprimé en Malaisie. Gedruckt in Malaysia. Impreso en Malasia. 0H2083A00 w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
Page 66
Printed in China. 中国印刷。 Imprimé en Chine. Gedruckt in China. Impreso en China. Printed on recycled paper. 0H2083A00 w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
