- Page 1 USER GUIDE Final Trim Size: 5.512 x 8.268 in. (140 x 210 mm) 3.3 Cu. Ft. 12 Volt Compact Refrigerator NS-CF12V33BK1 Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
Specifications ............17 ONE-YEAR LIMITED WARRANTY - INSIGNIA ......18... -
Page 3: Important Safety Instructions
3.3 Cu. Ft. 12 Volt Compact Refrigerator IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, explosion, electric shock, or injury when using your refrigerator, follow these basic safety precautions: • This refrigerator must be properly installed and located in accordance with the Installation Instructions before it is used. - Page 4 NS-CF12V33BK1 CAUTION: To reduce the risk of injury when using your refrigerator, follow these basic safety precautions. • Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impact, such as bumping or dropping.
- Page 5 3.3 Cu. Ft. 12 Volt Compact Refrigerator PROPER DISPOSAL OF YOUR OLD REFRIGERATOR WARNING: SUFFOCATION AND ENTRAPMENT HAZARD Failure to follow these disposal instructions can result in death or serious injury. IMPORTANT: Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators or freezers are still dangerous even if they will sit for “just a few days.”...
-
Page 6: Features
NS-CF12V33BK1 Features Package contents • 3.3 Cu. Ft. 12 Volt Compact Refrigerator • User Guide Dimensions 32.7 in. (83 cm) 18.5 in. (47 cm) 19.1 in. (48.5 cm) www.insigniaproducts.com... -
Page 7: Refrigerator Parts
3.3 Cu. Ft. 12 Volt Compact Refrigerator Refrigerator parts Thermostat control knob Top hinge Storage space Adjustable shelves Bottom shelf Bottle storage Crisper compartment Leveling feet Can Storage Installing your refrigerator Before using your refrigerator • Remove the exterior and interior packing. •... -
Page 8: Finding A Suitable Location
NS-CF12V33BK1 Finding a suitable location CAUTION: Your refrigerator is not designed for a recessed installation. • Place your refrigerator on a floor that’s strong enough to support your refrigerator when it is fully loaded. • Allow 1 in. (2.5 cm) of space between the back and sides of your refrigerator and any surrounding walls. -
Page 9: Providing Correct Ventilation
3.3 Cu. Ft. 12 Volt Compact Refrigerator Providing correct ventilation Place your refrigerator at least 1 in. (2.5 cm) from the wall to make sure that the airflow to the compressor is adequate. Don’t place your refrigerator near any heat sources, such as a heater or stove, because this may put a strain on the compressor. - Page 10 NS-CF12V33BK1 Remove the four screws in the lower rear refrigerator cover using a Phillips screwdriver. Screws Screws Cover Locate the power supply connection terminal block on the right side of the compressor compartment. Power input: DC 12 V Current: 15 A max.
-
Page 11: Reversing The Door Position
3.3 Cu. Ft. 12 Volt Compact Refrigerator Reversing the door position CAUTIONS: • To avoid serious injury or death from electrical shock, disconnect main DC power before you reverse the door. • To remove the door, you have to tilt your refrigerator backwards. To avoid personal injury and property damage, get another person to tilt your refrigerator while you reverse the door. - Page 12 NS-CF12V33BK1 Unscrew the left leveling foot, then remove it. Remove the screws that hold the bottom hinge and door stopper to your refrigerator, then remove the hinge and stopper. Install the leveling foot you removed from the left side into the right bottom of your refrigerator.
-
Page 13: Leveling Your Refrigerator
3.3 Cu. Ft. 12 Volt Compact Refrigerator Align the hole in the bottom left of the refrigerator door with the bottom hinge pin, then install the door on the hinge pin. Place the top hinge pin into the top of the refrigerator door, then install the top hinge on the top left of your refrigerator with the screws you removed previously. -
Page 14: Setting The Thermostat
NS-CF12V33BK1 Setting the thermostat Note: Your refrigerator’s temperature ranges from 32° to 46.4° F (0° to 8° C). The first time you turn your refrigerator on, adjust the thermostat to 7 and let your refrigerator cool at least 2 hours before putting foods inside. This makes sure that the cabinet is thoroughly chilled before food is put in. -
Page 15: Maintaining Your Refrigerator
3.3 Cu. Ft. 12 Volt Compact Refrigerator Maintaining your refrigerator Your refrigerator is designed for year-round use with only minimal cleaning and maintenance. When you first receive it, wipe the case with a mild detergent and warm water, then wipe dry with a dry cloth. Do this periodically to keep your refrigerator looking new. -
Page 16: Tips On Saving Energy
NS-CF12V33BK1 Tips on saving energy • Let hot foods cool before placing them in your refrigerator. Overloading your refrigerator forces the compressor to run longer. Foods that freeze too slowly may lose quality or spoil. • Wrap foods correctly and wipe containers dry before placing them in your refrigerator. -
Page 17: Specifications
3.3 Cu. Ft. 12 Volt Compact Refrigerator PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The door has been opened too often or Make sure that the door is closed correctly. was not closed correctly. Moisture is building up in Your refrigerator is in the interior of my a location that is very Move your refrigerator to a dryer location. -
Page 18: One-Year Limited Warranty - Insignia
Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Insignia and are not returned to you. - Page 19 Damage due to incorrect operation or maintenance • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Insignia to service the Product • Products sold “as is” or “with all faults” •...
- Page 20 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. V2 ENGLISH ©2020 Best Buy. All rights reserved.
