Summary of Contents for Powersmart PS8212
- Page 1 INSTRUCTION MANUAL 7.2A Electric String Trimmer Item: PS8212 Model # SF7A215 Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com Toll free: 1-800-791-9458 M-F 9-5 EST Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
59 x10.24 x4.7 inches Weight: 7.8 lb. Thank you for purchasing PowerSmart products. Please register online at www. Amerisuninc.com. The information will allow us to track your warranty and update on your unit. Important: Our company does not provide email or personal information to any third party for any reason. -
Page 4: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your string trimmer works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. - Page 5 • Keep all parts of your body away from any moving parts and all hot surfaces of the unit. • Check the work area before each use. Remove all objects such as rocks, broken glass, nails, wire, or string which can be thrown or become entangled in the machine. •...
-
Page 6: Electrical Information
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints, • Crystalline silica from bricks and cement and other masonry products, and • Arsenic and chromium from chemically-treated lumber. Your risk from these exposures varies, depending on how often you do this type of work. - Page 7 meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) Watts Power Minutes Time Safety Alert Precautions that involve your safety. Read the user’s To reduce the risk of injury, user must read and understand user’s manual manual before using this product.
- Page 8 SYMBOL SIGNAL MEANING DANGER Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury.
-
Page 9: Knowing Your String Trimmer
KNOWING YOUR STRING TRIMMER Motor housing Rear handle Front handle Trigger switch Shaft Lock off button Protector Trimmer head Guard Power cord Edger function switch Unpacking Unpack the string trimmer and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. - Page 10 WARNING: Do not use this product if any parts on the packing list are already assembled to your product when you unpack it. Parts on this list are not assembled to the product by the manufacturer and require customer installation. Use of a product that may have been improperly assembled could result in serious personal injury.
-
Page 11: Operating Instruction
Fig. 4 To fit the protector, insert the tails of the protector into the holes located on the press plate of guard (see Fig. 4). The protector will lift vertically when not in use. WARNING: Never use the product without the guard proper fitted. OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this string trimmer. - Page 12 WARNING: Disconnect the appliance from power source before performing adjustments. The PS8212 is designed to offer both trimming and edging function. To switch from trimming to edging, you pull the edger function switch backward (K) on the tool, and firmly holding the front handle (C) in other one hand and turn the tube to the left according to your need.
- Page 13 TRIMMING WARNING: Disconnect the appliance from power source before performing adjustments. Make sure that the work area is free of rocks, debris, lines and other foreign objects. 1. Hold the product firmly with a gap between the product and your right side. 2.
- Page 14 FITTING AND REPLACING LINE SPOOL ASSEMBLY WARNING: Disconnect appliance from power supply before performing adjustments. Only fit line spool recommended by the manufacturer. The line spool is already fit with the string trimmer when out of package. You need to replace it with new line when it’s used up.
-
Page 15: Maintenance
MAINTENANCE WARNING: In order to avoid personal injury and the risk of fire and electric shock, Disconnect appliance from power supply before adjusting, inspecting, or cleaning the string trimmer. CLEANING THE SPOOL HEAD Stop the motor and disconnect appliance from power supply. Clean dirt and debris from the spool head using a damp cloth with a mild detergent. -
Page 16: Troubleshooting
TROUBLE SHOOTING The following form lists the common operating system with problem and solutions. Please read the form carefully and follow it. PROBLEMS POSSIBLE CAUSES SOLUTION Product does not start 1. Not connect to power supply. 1. Connect to power supply. 2. -
Page 17: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 18 PS8212-038 Right housing Item Stock# Description PS8212-001 Spool cover PS8212-039 Cover PS8212-002 Nylon line PS8212-040 Screw ST4x16 PS8212-003 spool PS8212-041 Press plate PS8212-004 Balance weight PS8212-042 Power cord PS8212-005 Balance weight spring PS8212-043 ON/OFF trigger switch PS8212-006 Steel ball PS8212-044...
-
Page 19: Warranty
TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use.
