TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
Simple Shape TM technology-Set up and light up your tree in less than 10 minutes! Carefully follow the
instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Tree top
Section 3
Section 2
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective
cap before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into
the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all
wires are free of branch hinges.
7. Just plug the adaptor (connecting with the tree power cord) into the wall outlet (See Fig. B), your
entire tree should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or
broken, loose or missing bulbs. Replace bulbs promptly in order to maintain the performance and life
expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TG90P4444D00
Polygroup®!
This tree comes with Quick Set® and
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
Click
To close the stand, press the metal button
and fold the legs together.
*Electrical Rating For The Tree
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Control box
Insert Green
Label Extension
Cord into Adaptor
Side view
1
(For Indoor Use Only)
Input:120VAC, 60Hz, 0.45A
Output: 29V 0.9A
Adaptor
To Be Plugged
Into Wall
Outlet
