Polygroup TG90P4525D01 Assembly Instructions

TREE ASSEMBLY INSTRUCTIONS

Congratulations on purchasing your new tree from Polygroup®! This tree comes with Quick Set®
technology-Set up and light up your tree in less than 10 minutes! Carefully follow the instructions below
on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Eye Bolt
Fig. B - Tree and Light Assembly
Section 3
Section 2
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap
before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all
wires are free of branch hinges.
7. Just plug the adaptor (connecting with the tree power cord) into the wall outlet (See Fig. B), your
entire tree should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or
broken, loose or missing bulbs. Replace bulbs promptly in order to maintain the performance and life
expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TG90P4525D01
Eye Bolt
Click
Tree top
Control box
Side view
1. Pull apart the legs of the stand so that
they are snapped into an x-shape, place the
tree stand on a level surface.
2. When inserting the bottom section of the tree
into the assembled stand, insert and turn the
eyebolts into the stand and tighten until the
tree pole is firmly secured.
To close the stand, remove the eyebolts, press
the metal button and fold the legs together.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input:120VAC, 60Hz, 0.28A
Output: 29V DC 0.6A
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Foot Pedal
Adaptor
on/off Switch
To Be Plugged
Into Wall
Outlet
1
