TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
Quick Fold
and Simple Shape technology to make set up and storage quick and easy. Carefully follow the
TM
instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
3. Each tree section is numbered with a tag. Please identify all sections before assembling.
4. Assemble the tree from bottom to tree top. Start with the bottom section and remove the protective cap
before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into the stand.
SET UP
5.
• Remove tree stand and tree sections from box.
• Insert tree bottom section
• A. Locate "Pull Here" tab and corresponding Cinch Handle
B. Hold Cinch Clip firmly with one hand and press down on clip
C. With Cinch Clip depressed, pull clip away from tree until all
branches are released
D. Locate all clips on the same tree section then repeat above
procedures to release the corresponding branches.
• Remove the protective cap from tree bottom section
insert tree middle section 1
• Release all branches using the same procedures described in step 3.
• Add tree middle section 2
procedures described in steps 4 and 5.
6. Allow branches to fall into place or gently pull up and out. When
adjusting branches, be sure that all wires are free of branch hinges.
7. Just plug the adaptor (connecting with the tree power cord) into the wall outlet (See Fig. B), your entire tree
should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing
bulbs. Replace bulbs promptly in order to maintain the performance and life expectancy of your pre-lit tree.
MODEL #: TG90P4724D01
Polygroup®!
Click
4
3
2
1
5
into the tree stand
5
.
1
1
.
2
and tree top
using the same
3
4
This tree features Quick Set® and
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input:120VAC, 60Hz, 0.35A
Output: 29V DC 0.69A
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Control box
Cinch Clip
B
and
C
Cinch
PULL HERE
Handle
Do Not Tamper
Internal Parts
Open the
protective
cover
Adaptor
To Be Plugged
Into Wall
Outlet
A
